|$0
6138-72-1151
INJECTION PUMP ASS'Y
SN: 54720-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A,0461A,0462A,0471A AND FIGS.0481.
-1шт.
|$2
6138-72-1150
INJECTION PUMP ASS'Y
SN: 50195-54719
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451,0461,0462,0471,0481 AND 0491.
-1шт.
|$$5
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$5
DK105210-4690
FEED PUMP ASS'Y
SN: 50195-UP
1шт.
1
DK152051-0020
HOUSING
SN: 50195-UP
1шт.
2
DK152100-1120
PISTON
SN: 50195-UP
1шт.
3
DK152102-1600
SPRING,PISTON
SN: 50195-UP
1шт.
4
DK152105-1500
PLUG
SN: 50195-UP
1шт.
5
DK029332-6030
GASKET
SN: 50195-UP
1шт.
6
DK152111-2920
TAPPET ASS'Y
SN: 50195-UP
1шт.
7
DK152112-1000
ROLLER
SN: 50195-UP
1шт.
8
DK152113-0100
PIN
SN: 50195-UP
1шт.
9
DK152114-0700
GUIDE
SN: 50195-UP
2шт.
10
DK152115-0100
VALVE
SN: 50195-UP
2шт.
11
DK152116-0200
SPRING
SN: 50195-UP
2шт.
12
DK152117-0100
PLUG
SN: 50195-UP
1шт.
13
DK029331-6030
GASKET
SN: 50195-UP
1шт.
14
DK029631-6060
O-RING
SN: 50195-UP
1шт.
15
DK152121-0200
RING,SNAP
SN: 50195-UP
1шт.
16
DK152200-5420
PUMP,PRIMING
SN: 50195-UP
1шт.
17
DK152300-5920
BOLT,JOINT
SN: 50195-UP
1шт.
18
DK029731-4680
BOLT,JOINT
SN: 50195-UP
1шт.
19
DK029341-4130
GASKET
SN: 50195-UP
4шт.
20
DK152320-0100
COVER
SN: 50195-UP
1шт.
