|1
6215-71-1133
INJECTION PUMP A.,L.H.
SN: 10449-UP
1шт.
|1
0
INJECTION PUMP A.,L.H.
SN: 10304-10448
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B7A6¤C7A6Z¤D7A6Z¤ E7A6Z¤F7A6 AND FIG.A4010-G7A6.
-1шт.
|1
0
INJECTION PUMP A.,L.H.
SN: 10001-10303
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B7A6¤C7A6Y¤D7A6Y¤ E7A6Y¤F7A6 AND FIG.A4010-G7A6.
-1шт.
|1
0
INJECTION PUMP A.,L.H.
SN: (10001-10046)
1шт.
|$$7
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B7A6 TO A4010-G7A6.
-1шт.
|1
DK106068-2062
PUMP ASS'Y
SN: 10304-UP
1шт.
|$$9
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B7A6 AND A4010- C7A6Z.
-1шт.
|1
DK106068-2061
PUMP ASS'Y
SN: 10047-10303
1шт.
|$$11
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B7A6 AND A4010- C7A6Y.
-1шт.
|1
DK106068-2060
PUMP ASS'Y
SN: 10001-10046
1шт.
|$$13
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B7A6 AND A4010-C7A6.
-1шт.
1
DK134070-0420
HOUSING
SN: 10001-UP
1шт.
2
DK029040-6020
STUD
SN: 10001-UP
3шт.
3
DK134311-0000
RING
SN: 10001-UP
1шт.
4
DK134138-0100
STUD
SN: 10001-UP
12шт.
5
DK016650-2230
BEARING
SN: 10001-UP
1шт.
6
DK134303-0500
SHIM
SN: 10001-UP
1шт.
7
DK139006-4200
BOLT
SN: 10001-UP
4шт.
8
DK134340-0100
CAMSHAFT
SN: 10001-UP
1шт.
9
DK134306-1000
BEARING,CENTER
SN: 10001-UP
1шт.
10
DK020106-2040
BOLT
SN: 10001-UP
2шт.
11
DK134306-1100
BEARING,CENTER
SN: 10001-UP
2шт.
12
DK020106-2040
BOLT
SN: 10001-UP
4шт.
13
DK035302-0600
BEARING
SN: 10001-UP
1шт.
14
DK134316-3300
COVER
SN: 10001-UP
1шт.
15
DK139634-0200
SEAL,OIL
SN: 10001-UP
1шт.
16
DK134314-0700
SHIM¤ 0.10MM
SN: 10001-UP
-2шт.
|16
DK134314-0800
SHIM¤ 0.12MM
SN: 10001-UP
-2шт.
|16
DK134314-0900
SHIM¤ 0.14MM
SN: 10001-UP
-2шт.
|16
DK134314-1000
SHIM¤ 0.16MM
SN: 10001-UP
-2шт.
|16
DK134314-1100
SHIM¤ 0.18MM
SN: 10001-UP
-2шт.
|16
DK134314-1200
SHIM¤ 0.30MM
SN: 10001-UP
-2шт.
|16
DK134314-1300
SHIM¤ 0.50MM
SN: 10001-UP
-2шт.
17
DK139766-0000
O-RING
SN: 10001-UP
1шт.
18
DK134563-2500
SLEEVE
SN: 10001-UP
1шт.
19
DK134045-0100
PLUG
SN: 10001-UP
1шт.
20
DK026524-2940
GASKET
SN: 10001-UP
1шт.
21
DK139206-0400
NUT
SN: 10001-UP
3шт.
22
DK131041-0800
GASKET
SN: 10001-UP
1шт.
23
DK134047-0000
PLUG
SN: 10001-UP
6шт.
24
DK025806-2210
KEY
SN: 10001-UP
1шт.
25
DK014112-0440
WASHER,SPRING
SN: 10001-UP
1шт.
26
DK023012-0040
NUT
SN: 10001-UP
1шт.
27
DK156637-5900
COUPLING
SN: 10001-UP
1шт.
28
DK029731-4680
BOLT
SN: 10001-UP
1шт.
29
DK029341-4130
GASKET
SN: 10001-UP
2шт.
30
DK131424-7120
VALVE,OVER FLOW
SN: 10001-UP
1шт.
31
DK029341-4130
GASKET
SN: 10001-UP
2шт.
32
DK029731-4680
BOLT
SN: 10001-UP
1шт.
33
DK029341-4130
GASKET
SN: 10001-UP
2шт.
