|1
6222-71-1410
INJECTION PUMP A.
SN: 16016-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2B6 TO A4010-F2B6.
-1шт.
|1
ND090100-8380
BODY ASS'Y
SN: 16016-UP
1шт.
|$$4
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B2B6 AND A4010-C2B6.
-1шт.
1
ND090130-0540
HOLDER ASS'Y,DELIVERY VALVE
SN: 16380-UP
6шт.
|1
0
HOLDER ASS'Y,DELIVERY VALVE
SN: 16016-16379
6шт.
2
ND090136-0730
SPRING,DELIVERY VALVE
SN: 16016-UP
6шт.
3
ND949140-2570
O-RING
SN: 16016-UP
6шт.
4
ND090140-2020
VALVE,DELIVERY
SN: 16016-UP
6шт.
5
ND090150-4660
ELEMENT,PUMP
SN: 16016-UP
6шт.
6
ND090160-0150
SLEEVE,CONTROL
SN: 16016-UP
6шт.
7
ND090212-0471
RACK,CONTROL
SN: 16016-UP
1шт.
8
ND090163-0160
SEAT,UPPER SPRING
SN: 16016-UP
6шт.
9
ND090164-0250
SPRING,PLUNGER
SN: 16016-UP
6шт.
10
ND090165-0150
SEAT,LOWER SPRING
SN: 16016-UP
6шт.
11
ND090170-0320
TAPPET ASS'Y
SN: 16016-UP
6шт.
12
ND090438-0390
SHIM¤ 1.75MM
SN: 16016-UP
-2шт.
|12
ND090438-0400
SHIM¤ 1.8MM
SN: 16016-UP
-2шт.
|12
ND090438-0410
SHIM¤ 1.85MM
SN: 16016-UP
-2шт.
|12
ND090438-0420
SHIM¤ 1.9MM
SN: 16016-UP
-2шт.
|12
ND090438-0430
SHIM¤ 1.95MM
SN: 16016-UP
-2шт.
|12
ND090438-0440
SHIM¤ 2.0MM
SN: 16016-UP
-2шт.
|12
ND090438-0450
SHIM¤ 2.05MM
SN: 16016-UP
-2шт.
|12
ND090438-0460
SHIM¤ 2.1MM
SN: 16016-UP
-2шт.
|12
ND090438-0470
SHIM¤ 2.15MM
SN: 16016-UP
-2шт.
|12
ND090438-0480
SHIM¤ 2.2MM
SN: 16016-UP
-2шт.
|12
ND090438-0490
SHIM¤ 2.25MM
SN: 16016-UP
-2шт.
|12
ND090438-0500
SHIM¤ 2.3MM
SN: 16016-UP
-2шт.
|12
ND090438-0510
SHIM¤ 2.35MM
SN: 16016-UP
-2шт.
|12
ND090438-0520
SHIM¤ 2.4MM
SN: 16016-UP
-2шт.
13
ND949013-5880
WASHER,PLATE
SN: 16016-UP
12шт.
14
ND090139-0020
O-RING
SN: 16016-UP
18шт.
15
ND949018-1730
WASHER
SN: 16016-UP
6шт.
16
ND090248-0010
WASHER
SN: 16016-UP
1шт.
17
ND090244-0160
SCREW
SN: 16016-UP
1шт.
18
ND090114-0110
BUSHING
SN: 16016-UP
2шт.
19
ND090367-0040
BUSHING
SN: 16016-UP
1шт.
20
ND090018-0330
COVER
SN: 16016-UP
1шт.
21
ND949018-1550
WASHER
SN: 16016-UP
1шт.
