Запчасти Komatsu SA6D110-1F ТОПЛ. НАСОС (ТАЙМЕР) ТОПЛИВН. СИСТЕМА

|$0

6138-72-1600

INJECTION PUMP ASS'Y

SN: 50001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0491.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$3

DK105614-3070

TIMER ASS'Y

SN: 50001-UP

1шт.

1

DK156133-0520

HOLDER,FLYWEIGHT

SN: 50001-UP

1шт.

2

DK156108-6200

FLYWEIGHT

SN: 50001-UP

2шт.

3

DK029310-9030

SHIM, 0.10MM

SN: 50001-UP

-2шт.

3

DK139409-0000

SHIM, 0.15MM

SN: 50001-UP

-2шт.

3

DK029310-9040

SHIM, 0.20MM

SN: 50001-UP

-2шт.

3

DK029310-9010

SHIM, 0.50MM

SN: 50001-UP

-2шт.

3

DK029310-9020

SHIM, 1.00MM

SN: 50001-UP

-2шт.

3

DK029310-9050

SHIM, 1.50MM

SN: 50001-UP

-2шт.

4

DK156104-7600

SPRING

SN: 50001-UP

2шт.

5

DK156130-6520

FLANGE

SN: 50001-UP

1шт.

6

DK029622-8010

SEAL,OIL

SN: 50001-UP

1шт.

7

DK156114-1400

CASE

SN: 50001-UP

1шт.

8

DK156117-0100

O-RING

SN: 50001-UP

1шт.

9

DK156116-1920

SEAL,OIL

SN: 50001-UP

1шт.

10

DK131325-0400

NUT

SN: 50001-UP

1шт.

11

DK029321-4010

WASHER,SPRING

SN: 50001-UP

1шт.

12

DK156115-0100

PLUG

SN: 50001-UP

2шт.

13

DK026508-1240

GASKET

SN: 50001-UP

2шт.
