1
6271-31-2110
Piston, Standard
SN: 26501795-UP
4шт.
|1
6271-39-2110
Piston, Oversize 0.25mm
SN: 26501795-UP
4шт.
|1
6271-38-2110
Piston, Oversize 0.50mm
SN: 26501795-UP
4шт.
2
6207-31-2420
Pin, Piston
SN: 26501795-UP
4шт.
3
04065-03012
Ring, Snap
SN: 26501795-UP
8шт.
|4
6271-31-2100
Piston Ring Assembly, Standard
SN: 26501795-UP
4шт.
4
Ring, Top, Standard
SN: 26501795-UP
1шт.
5
Ring, Second, Standard
SN: 26501795-UP
1шт.
6
Ring, Oil, Standard
SN: 26501795-UP
1шт.
|6
6271-39-2100
Piston Ring Assembly, Oversize 0.25mm
SN: 26501795-UP
4шт.
|6
Ring, Top, Oversize 0.25mm
SN: 26501795-UP
1шт.
|6
Ring, Second, Oversize 0.25mm
SN: 26501795-UP
1шт.
|6
Ring, Oil, Oversize 0.25mm
SN: 26501795-UP
1шт.
|6
6271-38-2100
Piston Ring Assembly, Oversize 0.50mm
SN: 26501795-UP
4шт.
|6
Ring, Top, Oversize 0.50mm
SN: 26501795-UP
1шт.
|6
Ring, Second, Oversize 0.50mm
SN: 26501795-UP
1шт.
|6
Ring, Oil, Oversize 0.50mm
SN: 26501795-UP
1шт.
|7
6207-31-3800
Connecting Rod Assembly
SN: 26502022-UP
4шт.
7
6207-31-3810
Rod
SN: 26502022-UP
1шт.
8
6207-31-3130
Bushing
SN: 26501795-UP
1шт.
9
6204-31-3310
Bolt
SN: 26501795-UP
2шт.
|9
6208-31-3500
Crank Pin Metal Assembly, Standard
SN: 26502022-UP
4шт.
|9
6207-39-3900
Crank Pin Metal Assembly, Undersized, 0.25mm
SN: 26502022-UP
4шт.
|9
6207-38-3900
Crank Pin Metal Assembly, Undersized, 0.50mm
SN: 26502022-UP
4шт.
|9
6207-37-3900
Crank Pin Metal Assembly, Undersized, 0.75mm
SN: 26502022-UP
4шт.
|9
6207-36-3900
Crank Pin Metal Assembly, Undersized, 1.00mm
SN: 26502022-UP
4шт.
10
Metal,Upper
SN: 26501795-UP
4шт.
|10
Metal,Upper
SN: 26501795-UP
4шт.
|10
Metal,Upper
SN: 26501795-UP
4шт.
|10
Metal,Upper
SN: 26501795-UP
4шт.
|10
Metal,Upper
SN: 26501795-UP
4шт.
11
Metal,Lower
SN: 26502022-UP
4шт.
|11
Metal,Lower
SN: 26502022-UP
4шт.
|11
Metal,Lower
SN: 26502022-UP
4шт.
|11
Metal,Lower
SN: 26502022-UP
4шт.
|11
Metal,Lower
SN: 26502022-UP
4шт.
