|1
6222-73-1111
INJECTION PUMP ASS'Y
SN: 34724-UP
1шт.
|1
0
INJECTION PUMP ASS'Y
SN: 19030-34723
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B2D1 T0 A4010-G2D1.
-1шт.
|$$4
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND190100-0612
PUMP ASS'Y
SN: 34724-UP
1шт.
|1
ND190100-0610
PUMP ASS'Y
SN: 19030-34723
1шт.
|$$7
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B2D1 AND A4010-C2D1.
-1шт.
1
ND090130-0540
HOLDER ASS'Y,DELIVERY VALVE
SN: 19030-UP
6шт.
2
ND090136-0800
SPRING,DELIVERY VALVE
SN: 19030-UP
6шт.
3
ND949140-2570
O-RING
SN: 19030-UP
6шт.
4
ND090140-2440
VALVE,DELIVERY
SN: 19030-UP
6шт.
5
ND090150-6250
ELEMENT,PUMP
SN: 34724-UP
6шт.
|5
ND090150-5683
ELEMENT,PUMP
SN: 19030-34723
6шт.
6
ND090160-0150
SLEEVE,CONTROL
SN: 19030-UP
6шт.
7
ND090212-0471
RACK,CONTROL
SN: 19030-UP
1шт.
8
ND090163-0160
SEAT,UPPER SPRING
SN: 19030-UP
6шт.
9
ND090164-0290
SPRING,PLUNGER
SN: 19030-UP
6шт.
10
ND090165-0150
SEAT,LOWER SPRING
SN: 19030-UP
6шт.
11
ND090170-0320
TAPPET ASS'Y
SN: 19030-UP
6шт.
12
ND090438-0901
SHIM¤ 1.65MM
SN: 19030-UP
-2шт.
|12
ND090438-0911
SHIM¤ 1.7MM
SN: 19030-UP
-2шт.
|12
ND090438-0391
SHIM¤ 1.75MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0401
SHIM¤ 1.8MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0411
SHIM¤ 1.85MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0421
SHIM¤ 1.9MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0431
SHIM¤ 1.95MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0441
SHIM¤ 2.0MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0451
SHIM¤ 2.05MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0461
SHIM¤ 2.1MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0471
SHIM¤ 2.15MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0481
SHIM¤ 2.2MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0491
SHIM¤ 2.25MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
|12
ND090438-0501
SHIM¤ 2.3MM,ELEMENT HOLDER
SN: 19030-UP
-2шт.
13
ND90196-08651
NUT
SN: 19030-UP
12шт.
14
ND949013-5880
WASHER,PLATE
SN: 19030-UP
12шт.
15
ND90258-08001
WASHER
SN: 19030-UP
12шт.
16
ND090139-0020
O-RING
SN: 19030-UP
18шт.
17
ND949018-1730
WASHER
SN: 19030-UP
6шт.
18
ND90208-04610
WASHER¤ 0.1MM
SN: 19030-UP
-2шт.
|18
ND949013-5140
WASHER¤ 0.15MM
SN: 19030-UP
-2шт.
|18
ND949013-5930
WASHER¤ 0.3MM
SN: 19030-UP
-2шт.
19
ND090114-0110
BUSHING
SN: 19030-UP
2шт.
20
ND090367-0040
BUSHING
SN: 19030-UP
1шт.
