1
6251-31-2510
Piston
SN: 560016-UP
6шт.
2
6151-31-2410
Pin, Piston
SN: 560016-UP
6шт.
3
04065-04818
Ring, Snap
SN: 560016-UP
12шт.
|3
6251-31-2030
Ring Assembly, Piston
SN: 560016-UP
6шт.
4
Ring, Top
SN: 560016-UP
1шт.
5
Ring, Second
SN: 560016-UP
1шт.
6
Ring, Oil
SN: 560016-UP
1шт.
|6
6251-31-3100
Rod Assembly, Connecting
SN: 560016-UP
6шт.
7
Rod, Connecting
SN: 560016-UP
1шт.
8
Cap, Connecting Rod
SN: 560016-UP
1шт.
9
6251-31-3130
Bushing
SN: 560016-UP
1шт.
10
6150-31-3310
Bolt
SN: 560016-UP
2шт.
11
02400-10413
Pin, Dowel
SN: 560016-UP
2шт.
12
6151-31-3050
Metal Assembly, Standard
SN: 560016-UP
6шт.
|12
Metal, Upper Standard
SN: 560016-UP
1шт.
|12
Metal, Lower Standard
SN: 560016-UP
1шт.
|12
6151-39-3050
Metal Assembly, Undersize 0.25mm
SN: 560016-UP
6шт.
|12
Metal, Upper Undersize 0.25mm
SN: 560016-UP
1шт.
|12
Metal, Lower Undersize 0.25mm
SN: 560016-UP
1шт.
|12
6151-38-3050
Metal Assembly, Undersize 0.50mm
SN: 560016-UP
6шт.
|12
Metal, Upper Undersize 0.50mm
SN: 560016-UP
1шт.
|12
Metal, Lower Undersize 0.50mm
SN: 560016-UP
1шт.
|12
6151-37-3050
Metal Assembly, Undersize 0.75mm
SN: 560016-UP
6шт.
|12
Metal, Upper Undersize 0.75mm
SN: 560016-UP
1шт.
|12
Metal, Lower Undersize 0.75mm
SN: 560016-UP
1шт.
|12
6151-36-3050
Metal Assembly, Undersize 1.00mm
SN: 560016-UP
6шт.
|12
Metal, Upper Undersize 1.00mm
SN: 560016-UP
1шт.
|12
Metal, Lower Undersize 1.00mm
SN: 560016-UP
1шт.
