1
6261-31-2130
PISTON
SN: 530043-UP
6шт.
2
6211-31-2410
PIN,PISTON
SN: 530043-UP
6шт.
3
04065-05220
RING,SNAP
SN: 530043-UP
12шт.
|4
6261-31-2030
PISTON RING ASS'Y,PER CYLINDER
SN: 530043-UP
6шт.
4
0
RING,TOP
SN: 530043-UP
1шт.
5
0
RING,SECOND
SN: 530043-UP
1шт.
6
0
RING,OIL
SN: 530043-UP
1шт.
|7
6261-31-3100
CONNECTING ROD
SN: 530043-UP
6шт.
7
0
ROD,CONNECTING
SN: 530043-UP
1шт.
8
0
CAP,CONNECTING ROD
SN: 530043-UP
1шт.
9
6261-31-3140
BUSHING
SN: 530043-UP
1шт.
10
6210-31-3310
BOLT
SN: 530043-UP
2шт.
11
02400-10413
PIN,DOWEL
SN: 530043-UP
2шт.
|12
6210-32-3040
METAL ASS'Y,STANDARD
SN: 530043-UP
6шт.
|12
6210-39-3040
METAL ASS'Y,UNDERSIZE 0.25MM
SN: 530043-UP
6шт.
|12
6210-38-3040
METAL ASS'Y,UNDERSIZE 0.50MM
SN: 530043-UP
6шт.
|12
6210-37-3040
METAL ASS'Y,UNDERSIZE 0.75MM
SN: 530043-UP
6шт.
|12
6210-36-3040
METAL ASS'Y,UNDERSIZE 1.00MM
SN: 530043-UP
6шт.
12
0
METAL,LOWER¤ STANDARD
SN: 530043-UP
1шт.
|12
0
METAL,LOWER¤ UNDERSIZE 0.25MM
SN: 530043-UP
1шт.
|12
0
METAL,LOWER¤ UNDERSIZE 0.50MM
SN: 530043-UP
1шт.
|12
0
METAL,LOWER¤ UNDERSIZE 0.75MM
SN: 530043-UP
1шт.
|12
0
METAL,LOWER¤ UNDERSIZE 1.00MM
SN: 530043-UP
1шт.
13
0
METAL,UPPER¤ STANDARD
SN: 530043-UP
1шт.
|13
0
METAL,UPPER¤ UNDERSIZE 0.25MM
SN: 530043-UP
1шт.
|13
0
METAL,UPPER¤ UNDERSIZE 0.50MM
SN: 530043-UP
1шт.
|13
0
METAL,UPPER¤ UNDERSIZE 0.75MM
SN: 530043-UP
1шт.
|13
0
METAL,UPPER¤ UNDERSIZE 1.00MM
SN: 530043-UP
1шт.
