Запчасти Komatsu WB140PS-2 КАБИНА (/) ЧАСТИ КОРПУСА И КАБИНА
14
A
17
A
16
B
B
2
15
3
4
5
1
9
37
24
8
22
7
25
6
26
27
23
32
35
36
31
33
28
18
21
20
19
30
29
34
13
12
10
11
\0
312605125
OPERATOR'S CAB, ASSY
1
312605310
CABIN STRUCTURE
2
312605681
GLASS WINDOW, UPPER
3
312605680
GLASS WINDOW, LOWER
4
312605682
GLASS WINDOW, L.H.
5
312605715
GLASS WINDOW, R.H.
6
816214683
RIGHT DOOR, ASSY
7
312605730
GLASS DOOR, R.H.
8
816214589
FRAME, DOOR, R.H.
9
816214590
GASKET, DOOR, R.H.
10
816214682
LEFT DOOR, ASSY
11
312605731
GLASS DOOR, L.H.
12
816214591
FRAME, DOOR, L.H.
13
816214592
GASKET, DOOR, L.H.
14
816214685
RIGHT WINDOW, ASSY
15
312605713
GLASS WINDOW, R.H.
16
816214593
FRAME, WINDOW, R.H.
17
816214594
GASKET, WINDOW, R.H.
18
816214684
LEFT WINDOW, ASSY
19
312605714
GLASS WINDOW, L.H.
20
816214595
FRAME, WINDOW, L.H.
21
816214596
GASKET, WINDOW, L.H.
22
816213344
SPACER
23
801200700
BOLT
24
816213300
RUBBER
25
802070008
WASHER
26
816214635
NUT
27
801920051
COVER
28
312605687
GLASS-WINDOW, REAR
29
312605692
GLASS, LOWER, REAR
30
816214970
GASKET
31
816214669
FRAME, REAR WINDOW
32
816214600
GASKET
33
816214601
GASKET, LATERAL
34
816214598
GASKET
35
816214603
PLUG, FRAME, R.H.
36
816214604
PLUG, FRAME, L.H.
37
878000333
KIT, GLASS BONDING
