/ / / / / / FIG. T7-A ПОГРУЗ. КОВШ И РУКОЯТЬ
Запчасти Komatsu WB140PS-2N FIG. T7-A ПОГРУЗ. КОВШ И РУКОЯТЬ РАБОЧЕЕ ОБОРУДОВАНИЕ
14
13
19
17
10
17
12
19
11
14
3
4
16
7
15
3
5
15
9
1
22
27
23
28
24
22
25
26
21
25
29
28
26
30
6
8
5
14
12
13
20
27
31
2
18
14
12
13
15
16
1
312602052
ARM
2
390661002
BUSHING
3
500211029
BUSHING
4
390658012
BUSHING
5
860010007
FITTING, GREASE
6
312601665
PIN, ARM
7
390608003
SHIM (3 MM)
8
390608006
SHIM (1 MM)
9
802270019
RING, SNAP
11
801880212
NUT, SELF-LOCKING
12
312602600
LEVER
13
312602613
PIN, ARM/LEVER
14
390608002
SHIM (3 MM)
|$14
390608005
SHIM (1 MM)
15
802270017
RING, SNAP
16
860010007
FITTING, GREASE
17
312602612
LEVER, BUCKET
18
390661003
BUSHING
19
500211029
BUSHING
20
312602620
PIN, LEVER
21
801015700
BOLT
22
390605090
WASHER
23
801880224
NUT
24
WB14001FY
BUCKET (CUTTING EDGE)
|$28
WB14001ZY
BUCKET (NO CUTTING EDGE)
|$29
12F-70-31251
CUTTING EDGE FOR BUCKET
|$33
02090-11055
BOLT
|$37
02290-11016
NUT
|$41
20X-70-14151
ADAPTER
|$42
20X-70-14160
TOOTH
|$43
20X-70-14170
PIN
|$44
20X-70-14180
LOCK, PIN
25
312604609
PIN, ARM/LEVER TO BUCKET
27
801880212
NUT, SELF-LOCKING
28
860010007
FITTING, GREASE
29
NSS
TOOTH
30
NSS
BOLT
31
NSS
NUT
