A-AA БЛОК ЦИЛИНДРОВ

Запчасти Komatsu WB142-5 A-AA БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ

Схема запчастей Komatsu WB142-5 - A-AA БЛОК ЦИЛИНДРОВ ДВИГАТЕЛЬ
3
10
3
20
17
14
1
19
13
7
2
16
3
12
9
11
1
18
8
5
21
6
23
4
15
22
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

6731-22-1110

BLOCK KIT, CYLINDER

|$1

NSS

BLOCK, CYLINDER

1

6732-21-1810

PLUG, EXPANSION

2

6736-21-1820

PLUG, EXPANSION

3

6731-22-7140

PLUG, EXPANSION

4

6732-21-1611

BOLT

|$6

6754-21-1220

CAP, MAIN BEARING

5

6732-21-1910

DOWEL, RING

6

NSS

CAP, MAIN BEARING

7

NSS

BLOCK, CYLINDER

8

6732-21-1411

BUSHING

|$11

6731-21-1220

HARDWARE KIT, CYLINDER BLOCK

N/I

6732-21-1910

DOWEL, RING

9

6732-21-6120

DOWEL, PIN

10

6732-11-1920

PLUG, PIPE

|$15

6732-21-1960

PLUG, THREADED

11

NSS

PLUG, THREADED

12

6215-81-9710

SEAL, O-RING

N/I

6215-81-9710

SEAL, O-RING

13

6732-21-6130

PLUG, EXPANSION

14

6732-21-6140

DOWEL, RING

15

6732-21-1930

SEAL, O-RING

16

6732-21-6150

DOWEL, PIN

17

6732-21-5530

PLUG, EXPANSION

18

6732-21-6160

PLUG, EXPANSION

19

6745-11-1910

PLUG, PIPE

20

6735-21-5530

PLUG, EXPANSION

21

6731-21-1190

NOZZLE, PISTON COOLING

22

NSS

TAG, INSTRUCTION

23

6736-29-2110

SLEEVE, SALVAGE
