Запчасти Komatsu WB150AWS-2 ТРАНСМИССИЯ (7/) РАМА
A
A
19
18
10
6
8
11
6
7
19
4
9
10
12
2
5
14
17
1
13
3
15
16
\0
200120061
GEAR SHAFT, ASSY
1
CA0139348
SPRING
2
CA0139347
LOCK-SPRING COVER
3
CA0025021
LOCKRING
4
CA0140141
CLUTCH PISTON
5
CA0138372
SEAL RING
6
CA0028015
NEEDLE BEARING BUSH
7
CA0137825
SEAL RING
9
CA0133379
SPACER
10
CA0028350
BUSH
11
CA0138364
SEAL RING
12
CA0138398
COVER
13
CA0020852
BOLT
14
CA0024799
SNAP RING
15
CA0079175
THRUST WASHER
16
CA0026190
BEARING
17
CA0106866
SHIM 0.1 MM
17
CA0106867
SHIM 0.3 MM
17
CA0106868
SHIM 0.5 MM
18
CA0140117
BELLEVILLE WASHER
19
CA0140116
BELLEVILLE WASHER
