/ / / / / / FIG. F-A ТРАНСМИССИЯ - 1, 3, И 4 ПРИВОД МУФТАES
Запчасти Komatsu WB150AWS-2N FIG. F-A ТРАНСМИССИЯ - 1, 3, И 4 ПРИВОД МУФТАES СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА
13
12
11
5
3
14
2
1
11
4
12
10
10
9
9
28
8
13
7
16
14
6
15
21
17
20
24
27
26
18
19
37
20
29
39
25
16
15
23
36
5
38
22
40
36
7
8
28
37
35
10
45
9
34
44
43
33
42
32
41
31
30
1
CA0025053
LOCK RING
2
CA0125829
WASHER
3
CA0025809
BEARING
4
CA0139389
SPEEDOMETER DISC
5
CA0028041
NEEDLE BEARING
6
CA0138368
GEAR, 3RD
7
CA0025067
LOCK RING
8
CA0140332
LOCK RING
9
CA0133980
DRIVE PLATE
10
CA0138574
DISC PLATE
11
CA0138986
TRUST WASHER
12
CA0025031
LOCK RING
13
CA0133912
SPRING COVER
14
CA0129896
SPRING
15
CA0140126
CLUTCH PISON
16
CA0138790
SEAL RING
17
CA0138786
SEAL RING
18
CA0023834
PLUG
19
CA0028372
ROLLER
20
CA0024321
SPLIT PIN
21
CA0139392
SHAFT
22
CA0138366
GEAR, 4TH
23
CA0138365
GEAR, 1ST
24
CA0025066
LOCK RING
25
CA0138381
LOCK RING
26
CA0138377
DRIVE PLATE
27
CA0138378
DISC PLATE
28
CA0140116
BELLEVILLE WASHER
29
CA0140117
BELLEVILLE WASHER
30
CA0025021
LOCK RING
31
CA0139347
SPRING COVER
32
CA0139348
SPRING
33
CA0145898
CLUTCH PISTON
34
CA0145899
SEAL RING
35
CA0145900
SEAL RING
36
CA0028015
NEEDLE BEARING
37
CA0028350
BUSHING
38
CA0133379
SPACER
39
CA0138369
HOUSING AND GEAR
40
CA0138364
SEAL RING
41
CA0026190
BEARING
42
CA0079175
THRUST WASHER
43
CA0024799
SNAP RING
44
CA0138398
COVER
45
CA0020852
BOLT
