Запчасти Komatsu WB150PS-2N FIG. H7-A ЦИЛИНДР СТРЕЛЫ ГИДРАВЛИКА
2
3
8
4
9
5
10
6
21
7
9
11
22
19
1
17
20
18
13
16
14
2
15
12
1
395001010
BOOM CYLINDER
2
390658014
BUSHING
3
312305603
STOPPER, TUBE
4
804030055
SPRING
5
855150037
GASKET
6
390022007
PLUG
7
395081014
CYLINDER
8
391709001
PIN, BRAKE
9
805750022
BALL
10
395272015
PISTON
11
801476086
SCREW
12
395302016
HEAD, CYLINDER
13
395184015
ROD, SHAFT
|$13
878000541
GASKET KIT
14
NSS
GASKET
15
NSS
GASKET
16
NSS
GASKET
17
NSS
O-RING
18
NSS
RING
19
NSS
O-RING
20
NSS
O-RING
21
NSS
RING
22
NSS
GASKET
