/ / / / / / FIG. T7-A ЭКСКАВАТ. И КОВШ
Запчасти Komatsu WB150PS-2N FIG. T7-A ЭКСКАВАТ. И КОВШ РАБОЧЕЕ ОБОРУДОВАНИЕ
4
7
4
7
25
26
6
8
23
24
21
22
21
1
3
6
4
5
10
2
14
5
13
17
16
17
19
2
2
22
2
3
12
14
10
9
15
17
20
18
16
11
1
312709051
ARM
2
500217002
BUSHING
3
500217005
BUSHING
4
860010007
FITTING, GREASE
5
802610118
PIN, COTTER
6
312710052
PIN, LEVER
7
500217008
BUSHING
9
801880212
NUT, SELF-LOCKING
10
500270024
SPACER
11
390597064
PIN, ARM
12
802610118
PIN, COTTER (HAIRPIN)
13
CP12R02FY
BUCKET L=12 IN
|$13
CP16R02FY
BUCKET L=16 IN
|$14
CP18R02FY
BUCKET L=18 IN
|$15
CP24R02FY
BUCKET L=24 IN
|$16
CP30R02FY
BUCKET L=30 IN
|$17
20X-70-14151
ADAPTER
|$18
20X-70-14160
TOOTH
|$19
20X-70-14170
PIN
|$20
20X-70-14180
PIN, LOCK
14
200323390
PIN, BUCKET
15
NSS
TOOTH
16
NSS
BOLT
17
NSS
NUT
18
NSS
TOOTH
19
NSS
TOOTH
20
NSS
BOLT
21
802030505
NUT, RING
22
802040037
WASHER
23
312710050
LEVER, R.H.
24
312710051
LEVER, L.H.
25
500250056
SPACER
26
200703069
LEVER, ARM
