Запчасти Komatsu WB156PS-5 C-A КРЕПЛЕНИЕ РАДИАТОРА СИСТЕМА ОХЛАЖДЕНИЯ
4
6
31
3
7
33
2
32
30
5
9
11
28
1
5
33
12
33
7
29
9
8
10
15
25
14
24
26
27
35
24
17
23
22
23
21
19
18
10
34
20
13
16
1
42N-03-11412
TANK, RESERVE
2
22L-09-R3820
CAP
3
NSS
GASKET
4
22E-03-11270
HOSE
5
42N-03-11470
HOSE
6
08034-20519
STRAP, TIE
7
01016-50825
BOLT
8
21D-09-24180
NUT, STOP
9
01643-30823
WASHER
10
42N-03-11230
BAFFLE, FOAM
11
07285-00115
CLAMP
12
07285-00130
CLAMP
13
42N-03-11430
GUIDE
14
01010-80850
BOLT
15
01643-30823
WASHER
16
01580-10806
NUT
17
42N-03-11440
DRAIN VALVE
18
42N-03-11450
HOSE, DRAIN
19
07285-00150
CLAMP
20
42N-03-11420
BRACKET, SIDE
21
01643-30823
WASHER
22
01016-50825
BOLT
23
42N-01-11510
DAMPER
24
21D-09-73880
WASHER
25
01643-30823
WASHER
26
21D-09-24180
NUT, LOCK
27
01010-80850
BOLT
28
42N-06-12740
GROMMET
29
42N-03-12212
HOSE, TO ENGINE
30
42N-03-11460
GASKET
31
42N-03-12222
HOSE, FROM ENGINE
32
07289-00070
CLAMP
33
07289-00055
CLAMP
34
42N-03-11240
BAFFLE
