Запчасти Komatsu WB70A-1 КОРПУС РАБОЧЕЕ ОБОРУДОВАНИЕ
8
a
a
b
b
13
14
9
12
11
10
2
4
5
3
8
1
7
6
29
8
30
7
27
28
22
26
25
23
31
21
18
20
17
31
19
24
16
20
25
15
28
27
7
7
30
29
8
a
a
b
b
13
14
9
12
11
10
2
4
5
3
8
1
7
6
29
8
30
7
27
28
22
26
25
23
31
21
18
20
17
31
19
24
16
20
25
15
28
27
7
7
30
29
1
311903050
BRACKET
2
500111254
SLIDE BLOCK
3
311903300
SUPPORT
4
801014188
BOLT
5
802150516
SPRING WASHER
6
500216067
BUSHING
7
860010007
FITTING
8
500270016
SPACER
9
311901613
PIN
10
801015554
BOLT
12
311915055
PIN
13
816212241
KNOB
14
500270015
SPACER
15
311915054
SUPPORT
16
390616005
BUSHING
17
500252024
SPACER
18
802250045
SNAP RING
19
312315613
PIN
20
802250025
SNAP RING
21
311915053
STOPPER
22
816213544
KNOB
23
804030046
SPRING
24
801105536
SCREW
26
801105129
SCREW
27
500012363
COVER
28
855021829
O-RING
30
802170001
WASHER
31
500213510
BUSHING
1
311903050
BRACKET
2
500111254
SLIDE BLOCK
3
311903300
SUPPORT
4
801014188
BOLT
5
802150516
SPRING WASHER
6
500216067
BUSHING
7
860010007
FITTING
8
500270016
SPACER
9
311901613
PIN
10
801015554
BOLT
12
311915055
PIN
13
816212241
KNOB
14
500270015
SPACER
15
311915054
SUPPORT
16
390616005
BUSHING
17
500252024
SPACER
18
802250045
SNAP RING
19
312315613
PIN
20
802250025
SNAP RING
21
311915053
STOPPER
22
816213544
KNOB
23
804030046
SPRING
24
801105536
SCREW
26
801105129
SCREW
27
500012363
COVER
28
855021829
O-RING
30
802170001
WASHER
31
500213510
BUSHING
