Запчасти Komatsu WB97R-5 НАСОС ДЛЯ АВТОМАТИЧ. ТОПЛ. ЗАПРАВКИ КОМПОНЕНТЫ ДВИГАТЕЛЯ И ЭЛЕКТРИКА

\0

42N-06-15960

REFUELLING PUMP HARNESS, ASSY

1

42N-06-13410

REFUELLING PUMP HARNESS

2

42N-06-11380

WIRING HARNESS, SELF SUPPLY PUMP

3

01010-80614

BOLT

4

21D-09-24160

NUT, STOP

5

42N-04-11540

SUPPORT

6

01010-81025

BOLT

7

42N-06-11660

SUPPORT

8

37A-09-1U084

SCREW

9

01643-10623

SPRING WASHER

10

21D-09-21420

NUT

11

42N-54-12570

COVER, FRONT, L.H.

12

07281-00197

CLAMP

13

42N-04-11551

HOSE

14

21D-04-11420

HOSE

15

42N-04-11510

TANK

16

42N-04-11580

HOSE

17

07281-00167

CLAMP

18

20R-06-R1101

SEAL

19

42N-04-11590

SEAL

20

37A-09-4A013

WASHER

21

42N-04-11530

PIN

22

42N-04-11520

COVER

23

37A-09-51006

PIN, SAFETY

24

21D-04-11380

FUEL FILTER

25

21D-09-66610

ELBOW

26

37B-09-15617

O-RING
