Запчасти Komatsu WB98A-2 ГИДРОЛИНИЯ МОЛОТА (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ
1
A
B
D
E
C
B
A
30
C
D
E
A
B
1
4
29
3
14
12
13
13
12
14
28
2
1
30
3
30
5
3
31
22
28
21
20
19
22
18
6
6
21
11
39
23
10
1
9
17
38
7
17
12
34
14
8
32
16
33
15
13
36
28
35
37
26
25
20
26
19
25
27
24
1
392400017
HOSE
1
392400024
HOSE
2
802660508
CLAMP
3
392401015
HOSE
4
855051018
O-RING
5
312708621
SLEEVE
7
500380115
UNION
8
855051119
O-RING
9
855051021
O-RING
10
500380305
PLUG
11
855051021
O-RING
12
500380113
UNION
13
855051119
O-RING
14
855051018
O-RING
15
500380304
PLUG
16
855051018
O-RING
18
312743605
SUPPORT
20
802150510
SPRING WASHER
21
500380325
UNION, ASSY.
22
855051021
O-RING
23
500380315
PLUG
24
312743606
SUPPORT
25
500380324
UNION, ASSY.
26
855051018
O-RING
27
500380314
PLUG
28
392430032
HOSE
29
845190001
VALVE
30
392430022
HOSE
31
885180004
HOSE-CLAMP
32
500380213
UNION
33
855051217
O-RING
34
855051018
O-RING
35
200362254
COUPLING, ASSY.
36
200362255
FITTING
37
200362256
BODY
38
314503600
BRACKET
