8-СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН (/)

Запчасти Komatsu PC03-1 8-СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ

Схема запчастей Komatsu PC03-1 - 8-СЕКЦИОНН. УПРАВЛЯЮЩ. КЛАПАН (/) УПРАВЛ-Е РАБОЧИМ ОБОРУДОВАНИЕМ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
15
15
16
16
16
17
17
17A
17A
17B
17B
18
18
18
19
20
21
22
23
24
25
26
27
28
29
29
29A
29B
30
30
31
32
33
34
35
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

709-38-12401

VALVE ASS'Y

|$1

9\9709-38-12400

VALVE ASS'Y

|$2

709-38-11903

VALVE ASS'Y

|$3

709-38-11902

VALVE ASS'Y

|$4

700-28-58000

VALVE ASS'Y,MAIN RELIEF

1

SLEEVE

2

700-20-51430

SPRING

3

VALVE

4

700-20-51240

RING

5

700-80-61190

POPPET

6

700-20-51350

SPRING

7

700-20-51340

SCREW

8

01583-11408

NUT

9

07000-02011

O-RING

10

700-22-11410

O-RING

11

07002-02434

O-RING

|$16

709-30-64800

VALVE ASS'Y,SUCTION AND SAFETY

|$17

709-30-63901

VALVE ASS'Y,SUCTION AND SAFETY

|$18

709-30-63900

VALVE ASS'Y,SUCTION AND SAFETY

12

709-30-62110

SLEEVE

13

VALVE

13

VALVE

13

VALVE

14

SEAL

15

POPPET

15

POPPET

15

POPPET

16

SPRING

16

SPRING

17

PISTON

17

PISTON

17A

SCREW

17A

SCREW

17B

SEAL

18

O-RING

19

NUT

20

700-20-62170

SPRING

21

709-30-62290

PLUG

21

709-30-62150

PLUG

22

07002-12034

O-RING

23

07002-02034

O-RING

|$41

709-30-62201

VALVE ASS'Y,SUCTION AND SAFETY

|$42

709-30-62200

VALVE ASS'Y,SUCTION AND SAFETY

24

709-30-62110

SLEEVE

25

VALVE

25

VALVE

26

SEAL

27

POPPET

27

POPPET

28

SPRING

29

PISTON

29

PISTON

29A

SCREW

29B

SEAL

30

O-RING

31

NUT

32

700-20-62170

SPRING

33

709-30-62150

PLUG

34

07002-12034

O-RING

35

07002-02034

O-RING
