Запчасти Komatsu PC110R-1 КОЖУХ ШЕСТЕРЕН. ПЕРЕДАЧИ ДВИГАТЕЛЬ
18
10
30
11
29
26
27
30
12
13
14
25
23
17
9
19
15
28
5
6
20
8
24
19
24
22
3
23
1
16
21
4
30
A
\0
226-01-11000
MOTOR, ASSY.
1
YM723900-01570
HOUSING ASSY., GEAR
3
YM123900-01780
SEAL, OIL
4
YM123900-01740
COVER
5
YM26106-060162
BOLT PLATED
6
YM123900-01810
HOUSING ASSY., GEAR
8
YM123900-32000
OIL PUMP, ASSY.
9
YM26216-100302
STUD
10
YM121023-26070
COVER
11
YM24321-000850
O-RING
12
YM129900-32030
O-RING
13
YM129900-32040
O-RING
14
YM22312-080160
PIN
15
YM24341-000240
O-RING
16
YM26106-080202
BOLT PLATED
17
YM26106-080202
BOLT PLATED
18
YM26106-100222
SCREW
19
YM26106-080402
BOLT
20
YM26106-080452
BOLT
21
YM26106-080452
BOLT
22
YM26106-080502
SCREW
23
YM26106-080702
BOLT
24
YM26106-080802
BOLT
25
YM26366-100002
NUT
26
YM124160-01751
CAP, LUB. OIL SUPPLY
27
YM24311-000320
O-RING
28
YM121023-01550
COVER
29
YM24311-000110
O-RING
30
YM977770-01212
GASKET, LIQUID
