Запчасти Komatsu PC110R-1 БОКОВ. КРЫШКА ДВИГ. ЧАСТИ КОРПУСА И КАБИНА
15
7
17
35
12
6
9
8
9
1
10
3
4
8
2
5
2
14
9
3
34
13
16
2
35
3
9
14
9
11
32
33
31
19
21
18
20
30
23
8
29
28
27
9
22
8
9
26
9
24
25
a
b
b
a
1
226-54-11211
HOOD
2
01010-51025
BOLT
3
01643-31032
WASHER
4
21D-54-11590
GASKET
5
22E-54-11330
GASKET
6
21D-54-11970
GASKET
7
226-54-11230
COVER
8
01010-50820
BOLT
9
01643-30823
WASHER
10
226-54-11241
GASKET
11
226-54-11251
HOOD
12
226-54-11450
HINGE
13
21D-54-11192
DAMPER
14
21D-09-85140
PIN, COTTER
15
226-54-11312
HOOD
16
226-54-11440
GASKET
17
20M-54-72250
BOOT
18
22E-54-11650
PUSH-BUTTON, ASSY.
19
22E-54-11660
SPACER
20
21D-09-14120
SCREW
21
01580-10605
NUT
22
226-54-11130
LOCK, ASSY.
23
21D-09-15150
SCREW
24
01580-10806
NUT
25
22E-54-11360
SUPPORT
26
21D-54-11260
PIN
27
01643-31232
WASHER
28
22E-54-11270
NUT
29
21D-46-11150
TOOL BOX, ASSY.
30
21D-54-11750
GASKET
31
21D-54-11740
GASKET
32
226-54-11260
COVER
33
226-46-11180
GASKET
34
01010-50825
BOLT
35
22E-54-11370
GASKET
