Запчасти Komatsu PC120-5K ЦИЛИНДР РУКОЯТИ(№K-K) РАБОЧЕЕ ОБОРУДОВАНИЕ (ЭКСКАВАТ.)
1
2
3
3
4
5
6
7
8
8
9
9
10
11
12
13
14
15
15
16
17
18
19
20
20
21
21
22
23
24
25
26
27
27
28
28
29
30
31
32
33
33
34
34
35
35
36
36
37
37
|1
203-63-K1710
CYLINDER ASS'Y,ARM
1
203-63-K2010
CYLINDER
2
707-76-70240
BUSHING
3
07145-00070
SEAL,DUST
4
203-63-K2030
HEAD,CYLINDER
5
707-52-90500
BUSHING
6
707-51-75030
PACKING,ROD
7
707-51-75630
RING,BUFFER
8
203-63-K2060
O-RING
9
203-63-K2070
RING,BACK-UP
10
144-63-94170
SEAL,DUST
11
203-63-K2090
RING,SNAP
12
203-63-K2120
BOLT
13
203-63-K2020
ROD,PISTON
14
707-76-70240
BUSHING
15
07145-00070
SEAL,DUST
16
203-63-K2140
BUSHING,CUSHION
17
203-63-K2040
PISTON
18
203-63-K2080
O-RING
19
707-44-11280
RING,PISTON
20
707-39-11510
RING,WEAR
21
707-44-11920
RING
22
203-63-K2050
SCREW,SET
23
203-63-K2130
RING,CUSHION
24
203-63-K2110
RING,SNAP
25
203-63-K2660
TUBE
26
203-63-K2250
BLOCK
27
07000-13025
O-RING
28
203-63-K2240
BOLT
29
203-63-K2180
BAND
30
203-63-K2170
BRACKET
31
203-63-K2160
BAND
32
203-63-K2150
BRACKET
33
203-63-K2210
BOLT
34
203-63-K2220
WASHER
35
203-63-K2190
CLIP
36
203-63-K2790
NUT
37
203-63-K2230
WASHER
