/ / / / / / ОСНОВ. РУКОЯТЬ (SLIDE ПОДУШКА)(№-8)
Запчасти Komatsu PC120SC-6 ОСНОВ. РУКОЯТЬ (SLIDE ПОДУШКА)(№-8) РАБОЧЕЕ ОБОРУДОВАНИЕ
1
1
2
3
4
4
4
4
5
6
7
8
9
9
10
11
12
13
14
15
15
15
16
16
16
16
16
17
18
19
20
21
22
23
24
25
25
26
27
28
29
29
30
31
32
33
34
35
36
36
37
37
38
39
40
41
42
43
44
45
1
203-957-2240
PAD
2
203-957-2370
SHIM¤ 0.5MM
|2
203-957-2370
SHIM¤ 0.5MM
3
203-957-2380
SHIM¤ 1.0MM
|3
203-957-2380
SHIM¤ 1.0MM
4
203-957-2260
BRACKET
5
20Y-957-1210
NUT
6
01010-81230
BOLT
7
01643-31232
WASHER
8
01370-00616
SCREW
9
20Y-957-1220
PLATE
10
20Y-957-1230
RUBBER
11
01220-40412
SCREW
12
07020-00000
FITTING
13
203-957-2280
PAD
14
203-957-2390
SHIM¤ 0.5MM
|14
203-957-2390
SHIM¤ 0.5MM
15
203-957-2410
SHIM¤ 1.0MM
16
203-957-2270
BRACKET
17
20Y-957-1210
NUT
18
01010-81230
BOLT
19
01643-31232
WASHER
20
01370-00616
SCREW
21
203-70-56570
NIPPLE
22
07020-00900
FITTING
23
07020-00000
FITTING
24
20Y-25-11270
ELBOW
25
20Y-957-1220
PLATE
26
20Y-957-1230
RUBBER
27
01220-40412
SCREW
28
203-957-2330
PAD,L.H.
29
203-957-2340
PAD,R.H.
30
20Y-957-1350
NUT
31
01245-00616
SCREW
32
01010-81230
BOLT
|32
01010-81225
BOLT
33
01643-31232
WASHER
34
07020-00000
FITTING
35
203-957-2310
BRACKET,L.H.
36
203-957-2320
BRACKET,R.H.
37
20Y-957-1220
PLATE
38
20Y-957-1230
RUBBER
39
01220-40412
SCREW
40
01435-01235
BOLT
41
427-N96-1130
PLATE
42
203-957-2350
RUBBER
43
208-01-11270
WASHER
44
01010-81245
BOLT
45
01643-31232
WASHER
