NO. НАСОС, ВНУТР. ЧАСТИ (/) (№8-8)

Запчасти Komatsu PC1250SP-8 NO. НАСОС, ВНУТР. ЧАСТИ (/) (№8-8) NO. НАСОС

Схема запчастей Komatsu PC1250SP-8 - NO. НАСОС, ВНУТР. ЧАСТИ (/) (№8-8) NO. НАСОС
1
2
5
6
7
8
9
10
14
11
15
12
16
25
18
19
20
23
24
13
17
21
22
3
4
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$0

708-2L-00690

Pump Assembly

|$1

708-2L-01690

Pump Subassembly

|$2

708-2L-04940

Case Assembly,Rear

1

Case,Rear

2

Plug

3

07044-12412

Plug

4

07002-62434

O-ring

5

708-2L-21711

Cap, End

6

708-2L-32260

Bearing

7

07000-B2135

O-ring

8

6130-21-1910

Pin, Dowel

9

07000-B2015

O-ring

10

07000-B1009

O-ring

11

07000-B5165

O-ring

12

07000-B3032

O-ring

13

01252-61080

Bolt, Hexagon Socket Head

14

04530-11018

Bolt, Eye

15

708-25-13630

Ring

16

708-2L-22450

Shaft,Rear

17

708-2L-32150

Bearing

18

708-2E-05040

Washer Kit

18

Washer, T=3.1mm

18

Washer, T=3.0mm

18

Washer, T=2.9mm

18

Washer, T=2.8mm

19

708-25-12790

Ring, Snap

20

708-25-05021

Shim Kit

20

Shim, T=0.5mm

20

Shim, T=0.2mm

20

Shim, T=0.15mm

20

Shim, T=0.1mm

21

708-25-12950

Plate

22

01252-61040

Bolt, Hexagon Socket Head

23

01643-31032

Washer

24

01252-31016

Bolt

25

708-25-05130

Shim Kit

25

Shim, T=0.2mm

25

Shim, T=0.1mm
