/ / / / / / МЕХАНИЗМ ПОВОРОТА (ЗАДН.)
Запчасти Komatsu PC1250SP-8R МЕХАНИЗМ ПОВОРОТА (ЗАДН.) N
3
9
15
4
16
6
13
21
14
10
53
28
17
12
18
11
1
54
10
56
52
55
57
19
38
8
7
39
6
20
37
5
58
47
2
46
50
45
51
44
49
43
48
45
42
22
40
25
47
41
27
36
26
24
35
33
23
32
29
31
30
32
34
1
706-7K-01230
MOTOR ASS'Y
|$2
706-7K-01140
MOTOR ASS'Y
|$3
706-7K-01111
MOTOR ASS'Y
2
207-26-71240
RING
3
21N-26-33210
GAUGE
4
21N-26-33220
FILLER
5
07287-01012
HOSE
6
07285-00130
CLIP
7
208-871-5170
JOINT
8
07002-11223
O-RING
9
07030-00252
BREATHER
10
08034-40521
BAND
11
208-871-5161
BRACKET
12
07283-32738
CLIP
13
01597-01009
NUT
14
01643-31032
WASHER
15
01010-81030
BOLT
16
01643-31032
WASHER
17
01010-81240
BOLT
18
01643-31232
WASHER
19
21N-26-33190
CASE
20
07049-02430
PLUG
21
06000-23124
BEARING
22
21N-26-31140
BEARING
23
21N-26-31110
SHAFT, 13 TEETH
24
208-26-61291
OIL SEAL
25
21N-26-33230
COVER
26
01010-81030
BOLT
27
01643-31032
WASHER
28
07000-15390
O-RING
29
208-26-71181
CARRIER
30
208-26-71140
GEAR
31
207-27-61230
BEARING(2P)
32
20Y-27-21250
THRUST WASHER
33
207-27-61250
PIN
34
20Y-27-21290
PIN
35
208-26-71230
PLATE
36
205-32-51211
BOLT
37
208-26-71151
GEAR
38
01010-81645
BOLT
39
01643-31645
WASHER
40
208-26-71130
GEAR
41
208-26-71241
PLATE
42
208-26-71170
CARRIER
43
207-26-71520
GEAR
44
22U-26-21320
BEARING
