ОСНОВН. НАСОС (/)(NO. НАСОС)

Запчасти Komatsu PC1250SP-8R ОСНОВН. НАСОС (/)(NO. НАСОС) Y

Схема запчастей Komatsu PC1250SP-8R - ОСНОВН. НАСОС (/)(NO. НАСОС) Y
22
23
21
20
16
25
17
18
19
24
13
9
7
12
15
11
6
2
14
8
5
10
1
2
4
2
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

708-2L-00681

PUMP ASS'Y

|$2

708-2L-00680

PUMP ASS'Y

|$3

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$4

SHOWN IN FIGS.Y1600-01A0 TO Y1600-16A0.

|$5

708-2L-01680

PUMP ASS'Y

|$6

708-2L-04960

CASE ASS'Y,REAR

1

CASE,REAR

2

PLUG

3

07044-12412

PLUG

4

07002-62434

O-RING

5

708-2L-21540

CAP,END

6

708-2L-32260

BEARING

7

07000-B2135

O-RING

8

6130-21-1910

PIN,DOWEL

9

07000-B2015

O-RING

10

07000-B1009

O-RING

11

07000-B5165

O-RING

12

07000-B3032

O-RING

13

01252-61080

BOLT

14

04530-11018

BOLT,EYE

15

708-25-13630

RING

16

708-2L-22450

SHAFT,REAR

17

708-2L-32150

BEARING

18

708-2E-05040

WASHER KIT

|$25

WASHER,3.1MM

|$26

WASHER,3.0MM

|$27

WASHER,2.9MM

|$28

WASHER,2.8MM

19

708-25-12790

RING,SNAP

20

708-25-05021

SHIM KIT

|$31

SHIM,0.5MM

|$32

SHIM,0.2MM

|$33

SHIM,0.1MM

|$34

SHIM,0.1MM

21

708-25-12950

PLATE

22

01252-61040

BOLT

23

01643-31032

WASHER

24

01252-31016

BOLT

25

708-25-05130

SHIM KIT

|$40

SHIM,0.2MM

|$41

SHIM,0.1MM
