/ / / / / / ЦИЛИНДР СТРЕЛЫ(ДЛЯ ЭКСКАВАТ.)
Запчасти Komatsu PC1250SP-8R ЦИЛИНДР СТРЕЛЫ(ДЛЯ ЭКСКАВАТ.) Y
12
21A
11
52
14
13
14
25
22
23
24
21
16
20
19
17
18
33
46
32
33
36
47
37
2
48
41
8
50
47
9
47
51
49
54
4
44
34
45
5
7
55
53
9
44
8
45
38
10
40
35
47
46
3
5
6
4
39
43
1
42
31
30
15
29
27
26
28
29
|$1
707-F1-01380
CYLINDER ASS'Y
|$2
21N-63-02304
CYLINDER ASS'Y
|$3
==================
1
21N-63-52342
CYLINDER
2
21N-63-52321
ROD,PISTON
3
707-46-14010
BUSHING
4
21T-72-15860
BUSHING
5
21T-72-15870
SEAL,DUST (KIT)
6
07043-00108
PLUG
7
707-46-14010
BUSHING
8
21T-72-15860
BUSHING
9
21T-72-15870
SEAL,DUST (KIT)
10
07043-00108
PLUG
11
707-71-31820
COLLAR
12
707-71-11750
RING
13
07000-15220
O-RING (KIT)
14
07001-05220
RING,BACK-UP (KIT)
15
707-71-51750
PLUNGER
16
707-28-22711
HEAD,CYL.
|$20
707-28-22710
HEAD,CYLINDER
17
707-56-16740
SEAL,DUST
|$22
566-63-22241
SEAL,DUST (KIT)
18
07179-14180
RING,SNAP
19
707-51-16860
PACKING,ROD (KIT)
|$25
707-51-16030
PACKING,ROD (KIT)
20
707-51-16650
RING BUFFER (KIT)
|$27
707-51-16640
RING,BUFFER (KIT)
21
707-52-91351
BUSHING
21A
707-75-16110
RING,SNAP
22
07000-15220
O-RING (KIT)
23
707-35-92300
RING,BACK-UP
24
01011-83010
BOLT
25
01643-33080
WASHER
26
707-36-22300
PISTON
27
707-44-22250
RING,PISTON (KIT)
|$36
707-44-22280
RING,PISTON (KIT)
28
707-39-22800
RING, WEAR (KIT)
|$38
707-39-22820
RING,WEAR (KIT)
29
707-44-22920
RING
30
707-40-22870
SPACER
31
01252-61670
BOLT
32
07000-B5135
O-RING (KIT)
|$43
07000-15135
O-RING (KIT)
33
707-35-91440
RING,BACK-UP (KIT)
