Запчасти Komatsu PC12R-8 МОТОР ПОВОРОТА ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
16
17
17
18
18
19
19
20
20
21
21
22
22
23
23
24
24
25
25
26
26
27
27
28
28
29
29
30
30
31
31
32
32
32
32
33
33
34
34
35
35
36
36
36
36
37
37
38
38
39
39
40
40
41
41
42
42
43
43
44
44
45
45
46
46
46
46
46
46
47
47
48
48
49
49
50
50
51
51
52
52
53
53
54
54
55
55
56
56
|$0
20M-60-83001
MOTOR ASS'Y
1
STAD0898C
HOUSING,BEARING
2
STAD0882C
MOUNTING,FLANGE
3
STD0899B
GEAR,PINION
4
STA42041
PLUG
5
STAD0889B
PISTON
6
STAD0888B
RING
7
STAD0885B
PLATE
8
STAD0911A
PLATE
9
STAD0918B
PLATE
10
STAE134A-1
SPRING
11
STAA0006A-5
BEARING,FRONT
12
04065-01030
RING
13
04064-04518
RING
14
STAD0789A
BEARING,REAR
15
STAA0032A-47
RING
16
STADO320A
X-RING
17
07000-12015
O-RING
18
07000-12090
O-RING
19
STAA0033A-30
BOLT
20
ST9050
SEAL,SHAFT
21
ST7403CH-504
ROLLER
22
STD0633C-10
DRIVE
23
ST8432S-6
PLATE,VALVE
24
ST8433
SHAFT,VALVE
25
ST8915-1
RING,BALANCER
26
ST7383
SPRING
27
ST9135-1
SEAL,INNER FACE
28
ST14351
PIN
29
ST9135-2
SEAL,OUTER FACE
30
ST9022S-6
O-RING
31
ST9022S-2
O-RING
32
STAS568-011
O-RING
33
ST14314
BOLT
34
PLATE
35
RIVET,NAME
36
STDWD128A
PLUG
37
STAD0884A
COLLER
|$38
STAD0901C-001
VALVE HOUSING ASS'Y
38
HOUSING,VALVE
39
CARTRIDGE
40
VALVE,SEAT
41
VALVE,NEEDLE
42
SEAT,SPRING
43
WEIGHT,SPRING
44
PLUG,ORIFICE
45
PACKING
46
PLUG
47
SPRING
48
07000-11005
O-RING
49
07000-12020
O-RING
50
SCREW
51
NUT
52
NUT
53
PLUG
54
07000-12014
O-RING
55
SPRING
56
BALL,STEEL
