/ / / / / / ХОД MTOR (МОТОР В СБОРЕ) (/)
Запчасти Komatsu PC130-7 ХОД MTOR (МОТОР В СБОРЕ) (/) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
4
5
6
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
15
15
16
17
18
19
20
21
22
22A
23
24
25
26
27
28
29
30
31
32
32
33
34
35
36
37
38
39
40
41
42
43
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
|$0
203-60-63111
TRAVEL MOTOR ASS'Y
|$2
TZ276B200001JU
MOTOR
|$3
TZ276B210000-U
FLANGE ASS'Y
|$4
TZ276B210100-U
FLANGE KIT
1
FLANGE
2
SPOOL
3
TZGM1-8-S
PLUG
4
TZGDL1-16-S
PLUG
5
TZ263B2079-01
FILTER
6
TZ121F2070-00
ORIFICE
7
TZ850A0006-00
PLATE, NAME
8
TZ860A2051-00
PLUG
9
TZ869A2052-00
RETAINER
10
TZ860A2053-02
PLUG
11
TZ860A2054-01
VALVE
12
TZ860A2056-00
SPRING
13
TZ860A2055-01
SPRING
14
TZJB2401-P26-9
O-RING (K1)
15
07000-12016
O-RING (K1)
16
07000-12011
O-RING (K1)
17
TZ200B2073-00
VALVE
18
TZ300B2039-00
STOPPER
19
TZ300B2042-00
RING
20
TZ300B2043-01
SPRING
21
04260-00952
BALL
22
TZ512B2021-00
PLUG
22A
07000-12010
O-RING (K1)
23
04260-00793
BALL
24
TZ269B2002-00
SHAFT
25
TZ263B200301-J
PLATE
26
TZ263B2004-04
BLOCK
|$32
TZ263B2105-00
PISTON KIT
|$33
PISTON ASS'Y
27
PISTON
28
SHOE
29
TZ277B2007-00
PLATE
30
TZ263B2008-01
BOWL
31
TZ263B2009-01
PLATE
32
TZ880A2010-00
WASHER
33
TZ263B2011-03
WASHER
34
TZ266B2012-00
PISTON
35
TZ800A2013-00
SPRING
36
TZ277B2014-00
SPRING
37
TZ800A2015-00
PLATE
38
TZ800A2016-00
PLATE
39
TZ263B2074-00
PLATE
40
TZ100A2021-00
PLUG
41
TZ15Z-25-42-10
SEAL (K1)
42
TZ266B2035-00
O-RING (K1)
43
07000-12018
O-RING (K1)
44
TZ266B2039-00
O-RING (K1)
45
TZJB1354-4-10
PIN
46
TZJB1354-10-25
PIN
47
01252-31030
BOLT
48
TZTH-R-42
RING
49
TZ263B2048-00
BEARING
50
TZ263B2049-00
BEARING
51
TZ263B2098-00
PIN
|$59
TZ263B2070-01
PISTON
52
PISTON
53
SHOE
54
TZ263B2076-02
PIVOT
55
TZ263B2014-00
COLLAR
56
01252-30865
BOLT
57
TZ263B2077-01
PIN
58
07002-02034
O-RING (K1)
59
TZSW-M8
WASHER
60
TZ263B2090-00
SPRING
