/ / / / / / / МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА, (/)
Запчасти Komatsu PC130-8 МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА, (/) МОТОР ХОДА И КОНЕЧНАЯ ПЕРЕДАЧА
38
26
29
25
39
37
35
36
42
14
16
18
15
21
22
24
20
33
27
34
44
20
24
22
21
15
18
17
16
23
26
29
25
41
39
37
25
29
43
45
40
42
32
31
30
28
1
8
7
8
10
9
10
12
3
2
4
6
13
11
5
17
19
41
|1
22B-60-22111
Motor Assembly
|1
22B-60-22110
Motor Assembly
|1
TZ600D300000-A
Valve Assembly, Relief
|1
TZ600D310000-A
Valve Assembly, Relief
7
TZJB2401-P10A
O-ring
8
TZJB2407T2P10A
Ring, Back-up
9
07000-12014
O-ring
10
TZJB2407T2-P14
Ring
11
07000-12011
O-ring
12
07000-12018
O-ring
13
TZ247B3006-00
Shim
|14
TZ600D400001-B
Valve Assembly, Control
|14
TZ600D410001-B
Flange Assembly
|14
TZ600D410101-B
Flange Kit
|14
TZ600D415001-B
Spool Assembly
21
TZ600D4052-01
Washer
22
TZ100A2055-00
Spring
23
TZS0506
Orifice
24
07000-12032
O-ring
25
TZ200C2021-01
Plug
26
04260-00793
Ball
27
TZGDL1-16-S
Plug, Hexagon Head
28
TZ610B2021-00
Plug
29
07000-11008
O-ring
30
07000-12018
O-ring
31
TZ600D4069-00
Spool
32
TZ420B2089-01
Spring
33
TZS0505
Orifice
34
TZ976B2079-00
Filter
35
04260-00476
Ball
36
TZ571B2079-00
Plug
37
TZ200C2021-00
Plug
38
TZ600D4081-00
Piston
39
07000-12014
O-ring
40
TZS0545
Orifice
41
TZGM1-4-G-S
Plug
42
TZGM1-8-S
Plug, Hexagon Head
43
TZ850A0006-00
Plate, Name
44
TZJB1354-4-10
Pin
45
01252-31230
Bolt
|45
TZ600D9000-00
Service Kit
