Запчасти Komatsu PC130-8M0 МОТОР ХОДА (ГИДРАВЛ МОТОР) () [ХОД СИСТЕМА И ITS КОМПОНЕНТЫ]
![Схема запчастей Komatsu PC130-8M0 - МОТОР ХОДА (ГИДРАВЛ МОТОР) () [ХОД СИСТЕМА И ITS КОМПОНЕНТЫ]](https://www.partsell.ru/storage/images/komatsu/KC_EB010/p00361a.png)
116
115
135
112
139
109
341
377
354
301
327
330
331
326
325
328
336
324
103
106
106
107
108
151
104
110
114
110
145
113
150
376
323
327
380
383
358
352
353
329
398
396
343
353
358
352
381
383
380
366
363
359
357
398
399
384
210
210
208
208
201
207
209
212
378
379
398
330
331
326
325
328
336
324
203
204
202
213
206
211
205
167
171
185
161
162
132
149
102
|$1
TZ600D200002-B
Hydraulic Motor
|$2
TZ600D2205-01
Cylinder&Piston Kit
|$3
Piston Kit
|$4
Piston Assembly
105
Piston
106
Shoe
104
Cylinder Block
|$8
TZ600D2070-01
Piston Assembly
161
Piston
162
Shoe
102
TZ600D2002-01
Shaft
103
TZ600D200300-B
Swash Plate
107
TZ600D2007-01
Retainer Plate
108
TZ600D2008-00
Thrust Ball
109
TZ600D2009-01
Timing Plate
110
TZ880A2010-00
Washer
112
TZ600D2012-00
Piston
113
TZ500D2013-00
Spring
114
TZ600D2014-00
Spring
115
TZ600D2015-00
Friction Plate
116
TZ600D2016-00
Opposite Plate
132
TZTCZ284810113
Oil Seal
135
TZ500D2039-00
O-ring
139
TZ600D2039-00
O-ring
145
TZTH-R-42
Thrust Snap Ring
149
TZ600D2048-00
Deep-groove Ball Bearing
150
06000-06304
Deep-groove Ball Bearing
151
TZJB15063-258F
Needle Roller Bearing
167
TZ600D2076-01
Pivot
171
TZ263B2077-01
Parallel Pin
185
TZ600D2090-00
Spring
|$32
TZ600D300000-A
Relief Valve
|$33
TZ600D310000-A
Relief Valve Assembly
201
Valve Seat
202
Valve
203
Sleeve
204
Collar
