ТОПЛ. НАСОС (НАСОС) (/) (ВНУТР. ЧАСТИ)

Запчасти Komatsu PC130F-7 ТОПЛ. НАСОС (НАСОС) (/) (ВНУТР. ЧАСТИ) A

Схема запчастей Komatsu PC130F-7 - ТОПЛ. НАСОС (НАСОС) (/) (ВНУТР. ЧАСТИ) A
23
25
24
25
12
4
14
1
13
6
5
3
20
19
8
7
18
13
14
12
15
22
16
2
21
9
10
11
17
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

6208-71-1210

INJECTION PUMP

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$3

SHOWN IN FIGS.A4010-B0W8 TO A4010-F0W8.

|$4

DK101049-4120

PUMP ASS'Y

|$5

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$6

SHOWN IN FIGS.A4010-B0W8 AND A4010-C0W8.

1

DK131063-9920

HOUSING

2

DK029040-6020

STUD

3

DK131400-0100

ADAPTER

4

DK131002-2000

ADAPTER

5

DK131028-6220

COVER

6

DK131011-1900

GASKET

7

DK131017-1000

SCREW

8

DK029340-6020

GASKET

9

DK139206-0400

NUT

10

DK029633-1010

O-RING

11

DK131360-3000

CAMSHAFT

12

DK016630-2030

BEARING

|$19

DK028201-7020

BEARING

13

DK131302-0300

RING

14

DK029311-7010

SHIM, 0.1MM

|$22

DK029311-7020

SHIM, 0.12MM

|$23

DK029311-7030

SHIM, 0.14MM

|$24

DK029311-7040

SHIM, 0.16MM

|$25

DK029311-7050

SHIM, 0.18MM

|$26

DK029311-7090

SHIM, 0.3MM

|$27

DK029311-7060

SHIM, 0.5MM

|$28

DK029311-7210

SHIM, 0.7MM

|$29

DK029311-7070

SHIM, 1.0MM

|$30

DK029311-7220

SHIM, 1.4MM

|$31

DK139417-0000

SHIM, 2.40MM

15

DK029621-7050

SEAL,OIL

16

DK131330-6200

COVER

17

DK020006-1440

BOLT

18

DK025803-1640

KEY

19

DK131401-0020

BOLT,EYE

20

DK029341-4130

GASKET

21

DK029731-0120

BOLT,EYE

22

DK029341-0110

GASKET

23

DK131425-1420

VALVE

24

DK139814-0500

EYE

25

DK029341-4130

GASKET
