ОСНОВН. НАСОС (8/8)

Запчасти Komatsu PC130F-7 ОСНОВН. НАСОС (8/8) Y

Схема запчастей Komatsu PC130F-7 - ОСНОВН. НАСОС (8/8) Y
13
12
11
16
23
9
8
10
18
19
17
24
15
1
25
1
3
8
14
4
18
3
22
19
21
20
2
7
6
5
3
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

708-1L-00651

PUMP ASSY

|$2

708-1L-00650

PUMP ASS'Y

|$3

THIS ASSEMBLY CONSISTS OF ALL PARTS

|$4

SHOWN IN FIGS.Y1600-01A0 T0 Y1600-08A0.

1

702-21-07311

VALVE ASS'Y, EPC

|$6

708-2L-04291

BLOCK ASS'Y

2

BLOCK

3

PLUG

4

708-2L-23970

O-RING

5

07040-11007

PLUG

6

07002-61023

O-RING

7

01252-60865

BOLT

8

203-60-62220

BOLT

9

21W-62-43960

ELBOW

10

07002-61423

O-RING

11

02896-61008

O-RING

12

02781-0021D

UNION

13

07002-61423

O-RING

14

02896-61008

O-RING

15

01582-11008

NUT

16

708-1L-29361

HOSE

17

708-1L-29350

HOSE

18

708-2L-23960

O-RING

19

07000-B2011

O-RING

20

825-56-24360

ELBOW

21

07002-61423

O-RING

22

708-1L-29340

ORIFICE

23

02896-61008

O-RING

24

20Y-62-22790

BAND, RED

25

20Y-62-22830

BAND, WHITE
