КАБИНА (КРЫША COVER)

Запчасти Komatsu PC160LC-8 КАБИНА (КРЫША COVER) K

Схема запчастей Komatsu PC160LC-8 - КАБИНА (КРЫША COVER) K
5
3
4
1
2
12
13
9
6
8
27
28
7
20
11
10
13
14
15
16
18
17
26
22
25
19
16
19
16
21
22
24
23
32
34
33
30
29
31
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

21K-53-00121

CAB ASS'Y (WITH AC)

|$2

21K-53-00190

CAB ASS'Y (WITHOUT AC)

1

20Y-53-12412

COVER (ROOF)

2

09416-10200

RIVET

3

20Y-53-12421

COVER (ROOF/REAR)

4

09416-10200

RIVET

5

20Y-53-13870

SEAL

6

20Y-53-12431

COVER (L.H)

7

208-53-13270

RIVET

8

01435-00612

BOLT

9

20Y-53-12710

SEAL

10

20Y-53-12441

COVER (R.H)(FOR CAB WITH AC)

|$13

20Y-53-12442

COVER (R.H)(FOR CAB WITHOUT AC)

11

09416-10200

RIVET

12

01435-00612

BOLT

13

20Y-53-12710

SEAL

14

20Y-53-12552

SEAL

15

20Y-53-12463

COVER (L.H)(FOR CAB WITH AC)

|$19

2A5-53-11291

COVER (L.H)(FOR CAB WITHOUT AC)

16

20Y-53-12310

COLLAR

17

01245-00616

SCREW

18

01643-70623

WASHER

19

01435-00612

BOLT

20

22B-54-17380

HAMMER (FOR CAB WITH AC)

|$25

20Y-53-15480

HAMMER (FOR CAB WITHOUT AC)

21

20Y-53-12472

COVER (R.H)

22

20Y-53-12310

COLLAR

23

01245-00616

SCREW

24

01643-70623

WASHER

25

01435-00612

BOLT

26

09415-00706

CAP (FOR CAB WITHOUT AC)

27

205-54-51250

HANGER

28

01370-30416

SCREW

29

208-53-12991

HOLDER (CUP)

30

208-53-12980

PLATE

31

01023-20616

SCREW

32

20Y-53-11752

COVER

33

01435-40610

BOLT

34

20Y-53-11761

LOCK ASS'Y
