/ / / / / / ОСНОВН. НАСОС (8/) (ПОВОРОТН. НАСОС)
Запчасти Komatsu PC1800-6-M1 ОСНОВН. НАСОС (8/) (ПОВОРОТН. НАСОС) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
2
3
4
5
6
7
8
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
26
27
27
27
28
29
30
31
31
32
33
34
35
36
37
|1
708-1H-00320
PUMP ASS'Y
|1
708-17-07140
SERVO VALVE ASS'Y,FRONT
|1
708-17-07540
VALVE ASS'Y,CO + NC
|1
708-23-00430
BODY ASS'Y
1
BODY
2
EXPANDER
3
708-25-17460
PLUG
4
708-25-17430
SCREW
5
07000-B2010
O-RING
6
708-25-17131
COVER
7
01580-10806
NUT
8
708-25-17141
SPOOL
9
708-25-17150
SLEEVE
10
708-25-17160
PISTON
11
708-25-17170
COVER
12
07000-B2014
O-RING
13
708-25-17180
SEAT
14
708-25-17690
SPRING
15
708-25-17451
SLEEVE
16
708-25-17220
PISTON
17
708-25-17370
SEAT
18
708-25-17250
SPRING
19
708-25-17260
SEAT
20
708-25-17410
PLUG
21
07000-B1009
O-RING
22
07000-B3028
O-RING
23
708-25-17350
COVER
24
708-25-15340
SCREW
25
708-25-15320
BOLT
26
708-25-15320
BOLT
27
01602-20619
WASHER
28
01580-10806
NUT
29
07000-B2012
O-RING
30
07000-B2012
O-RING
31
07001-02012
RING,BACK-UP
32
708-25-15320
BOLT
33
01602-20619
WASHER
34
07000-B2021
O-RING
35
07001-02021
RING,BACK-UP
36
07040-11007
PLUG
37
708-2L-23920
O-RING
