/ / / / / / ЦИЛИНДР СТРЕЛЫ, L.H ( ЧАС.)(ВНУТР. ЧАСТИ)(J97-UP)
Запчасти Komatsu PC195LC-8 ЦИЛИНДР СТРЕЛЫ, L.H ( ЧАС.)(ВНУТР. ЧАСТИ)(J97-UP) T
11
9
11
8
17
18
20
19
16
12
15
13
14
21
22
44
45
43
36
37
38
39
32
41
3
4
5
42
49
48
1
27
26
25
23
24
25
26
29
28
10
29
40
30
35
34
50
51
31
52
47
46
33
53
4
2
7
6
7
|$1
707-01-XCK20
CYLINDER GROUP, L.H
|$2
707-01-0CK20
CYLINDER ASS'Y
1
707-13-11790
CYLINDER
2
707-58-75650
ROD, PISTON
3
707-76-70230
BUSHING
4
07145-00070
SEAL, DUST (KIT-K07)
5
07020-00000
FITTING, GREASE
6
707-76-70230
BUSHING
7
07145-00070
SEAL, DUST (KIT-K07)
8
707-71-32580
COLLAR
9
07000-15100
O-RING (KIT-K07)
10
707-71-70810
PLUNGER
11
707-35-91130
RING, BACK-UP (KIT-K07)
12
707-27-11650
HEAD, CYLINDER
13
707-56-75740
SEAL, DUST (KIT-K07)
14
07179-13089
RING, SNAP
15
707-51-75030
PACKING, ROD (KIT-K07)
16
707-51-75650
RING, BUFFER (KIT-K07)
17
07000-15100
O-RING (KIT-K07)
18
707-35-91130
RING, BACK-UP (KIT-K07)
19
707-52-90501
BUSHING
20
707-75-75110
RING, SNAP
21
01010-81670
BOLT
22
01643-51645
WASHER
23
721-36-11020
PISTON
24
707-44-11150
RING, PISTON (KIT-K07)
25
707-39-11150
RING, WEAR (KIT-K07)
26
707-44-11911
RING
27
01310-01216
SCREW
28
07000-15070
O-RING (KIT-K07)
29
707-35-90360
RING, BACK-UP (KIT-K07)
30
707-86-68270
TUBE, L.H
31
02896-61015
O-RING (KIT-K07)
32
707-86-66780
TUBE, L.H
33
02896-61018
O-RING (KIT-K07)
34
01010-80840
BOLT
35
01643-30823
WASHER
36
07372-21060
BOLT
37
01643-51032
WASHER
38
07372-21045
BOLT
39
01643-51032
WASHER
40
07000-13025
O-RING (KIT-K07)
41
07000-13030
O-RING (KIT-K07)
42
707-88-22910
BRACKET, L.H
43
707-88-21640
BAND
