ГЕНЕРАТОР, AMP

Запчасти Komatsu PC195LC-8 ГЕНЕРАТОР, AMP A

Схема запчастей Komatsu PC195LC-8 - ГЕНЕРАТОР, AMP A
4
2
1
7
6
3
5
19
20
21
28
13
10
17
14
18
30
27
29
22
23
17
26
8
24
9
11
16
15
25
12
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

|$1

600-861-3420

ALTERNATOR ASS'Y, 35 AMP

|$2

FRAME ASS'Y

1

STATOR ASS'Y

2

FRAME

3

PLATE

4

COLLAR

5

SCREW

6

BEARING, BALL

7

BOLT

8

FRAME

9

RECTIFIER ASS'Y

10

BRUSH HOLDER ASS'Y

11

REGULATOR ASS'Y

12

COVER

13

BUSHING

14

BUSHING

15

SCREW

16

SCREW

|$19

SCREW

17

NUT

18

NUT

19

ROTOR ASS'Y

20

BEARING, BALL

21

COVER

22

PULLEY

23

NUT

24

SEAL

25

SEAL

26

WASHER

27

SCREW

28

SCREW

29

PLATE

30

NUT
