Запчасти Komatsu PC200-6B ТОПЛИВНАЯ ЛИНИЯ (OLD) ТОПЛИВН. БАК. AND КОМПОНЕНТЫ
5
6
30
31
10
8
8
9
14
15
13
7
28
29
28
27
1
20
19
18
19
17
16
4
3
22
2
32
21
11
12
46
39
35
44
45
47
44
45
37
48
49
50
51
49
3
22
41
40
36
24
26
23
34
39
25
44
36
45
41
41
42
38
37
44
45
45
45
43
41
34
33
39
39
1
600-311-9101
FUEL FILTER ASS’Y
2
20Y-04-21630
JOINT
3
07005-01412
GASKET
4
07206-31014
JOINT
5
01010-81030
BOLT
6
01643-31032
WASHER
7
600-311-9731
WATER SEPARATOR A.
8
07005-01412
GASKET
9
07206-31014
BOLT
10
20Y-04-21630
JOINT
11
01010-81030
BOLT
12
01643-31032
WASHER
13
20Y-04-21211
BRACKET
14
01010-81225
BOLT
15
01643-31232
WASHER
16
103-04-22150
NIPPLE
17
07700-40240
VALVE
18
205-04-62140
JOINT
19
07005-01412
GASKET
20
07206-31014
BOLT
21
07288-01214
HOSE
22
07281-00197
CLAMP
23
08034-00519
BAND
24
141-06-11220
CLIP
25
01010-81225
BOLT
26
01643-31232
WASHER
27
07288-01203
HOSE
28
07281-00197
CLAMP
29
20Y-04-21630
JOINT
30
07005-01412
GASKET
31
07206-31014
JOINT
32
08036-01814
CLIP
33
07288-00831
HOSE
34
07288-01229
HOSE
35
07288-01205
HOSE
36
08034-00519
BAND
37
205-62-53780
COVER
38
08034-00834
BAND
39
07281-00197
CLAMP
40
20Y-04-21151
BRACKET
41
04435-51912
CLIP
42
142-03-11160
SPACER
43
01010-81260
BOLT
44
01010-81225
BOLT
45
01643-31232
WASHER
46
6995-71-1340
ELBOW
47
207-04-A1100
STRAINER ASS’ Y
48
23S-62-25850
CLIP
49
08036-01414
CLIP
50
01010-81020
BOLT
51
01643-31032
WASHER
