/ / / / / / ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№9999-8)
Запчасти Komatsu PC200-6Z ОСНОВН. КЛАПАН (-АКТУАТОР) (/)(№9999-8) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
7
7
7
7
7
8
8
9
9
9
9
9
9
9
9
10
10
11
11
12
12
13
13
14
14
14
14
14
14
14
14
15
15
15
15
15
15
15
15
16
16
17
17
17
17
18
18
18
18
19
19
19
20
20
20
20
20
20
20
20
20
20
21
21
21
21
21
21
21
21
21
21
21
21
22
22
22
22
22
22
22
22
23
23
24
24
25
26
26
27
28
28
29
29
29
29
30
30
31
31
32
32
32
33
33
34
34
35
36
37
37
38
38
39
40
40
41
42
42
43
44
45
46
47
48
48
49
|1
723-47-13304
VALVE ASS'Y
|1
723-47-13303
VALVE ASS'Y
|1
723-47-13302
VALVE ASS'Y
|1
BODY SUB ASS'Y
|1
BODY SUB ASS'Y
|1
BODY SUB ASS'Y
1
BLOCK,VALVE
2
SPOOL
3
SPOOL
|3
SPOOL
4
SPOOL
|4
SPOOL
5
SPOOL
6
SPOOL
|6
SPOOL
7
723-46-15130
PLUG
8
723-46-15140
PLUG
9
07002-10823
O-RING
10
723-46-16171
PLUG
11
07002-11023
O-RING
12
07000-11005
O-RING
13
07001-01005
RING,BACK-UP
14
708-7T-16460
BALL
15
723-46-15120
RETAINER
16
723-46-16160
RETAINER
17
723-46-14110
SPRING
18
723-46-14170
SPRING
|18
723-46-14170
SPRING
19
723-46-14131
SPRING
|19
723-46-14131
SPRING
20
723-46-15110
CASE
21
07430-71380
O-RING
22
01252-60820
BOLT
23
01252-60860
BOLT
24
723-46-16110
CASE
25
723-46-16120
PISTON
26
723-46-16130
PISTON
27
723-46-16140
PISTON
28
723-46-16152
PISTON
29
723-46-16180
SEAL
30
702-16-54490
SCREW
31
723-46-16190
NUT
32
PLUG
33
723-46-15150
VALVE
34
723-46-14150
SPRING
35
708-8H-11530
PLUG
36
07002-11423
O-RING
37
723-46-41110
VALVE
38
723-46-41120
VALVE
|39
723-46-00710
CASE SUB ASS'Y
39
CASE
40
PISTON
41
PISTON
42
SEAL
43
SCREW
|44
723-46-00720
CASE SUB ASS'Y
44
CASE
45
PISTON
46
PISTON
47
PISTON
48
SEAL
49
SCREW
