Запчасти Komatsu PC200-8M0 ОСНОВНАЯ РАМА(LOGGING) J
9
10
8
7
27
25
13
14
11
4
5
2
13
14
12
21
23
26
22
16
17
18
19
15
24
6
20
1
3
1
20Y-46-J1620
FRAME
2
205-30-71181
COVER
3
205-30-71191
GASKET
4
01010-81230
BOLT
5
01643-31232
WASHER
6
20Y-46-41280
PLUG
7
206-06-22140
BRACKET
8
207-06-51330
SHEET
9
01010-81230
BOLT
10
175-54-34170
WASHER
11
20Y-54-61670
BRACKET
12
20Y-54-61680
BRACKET
13
01010-81230
BOLT
14
01643-31232
WASHER
|$15
20Y-46-52441
COVER
15
20Y-46-52190
COVER
16
20Y-46-52180
SHEET
17
20Y-46-52172
SHEET
18
01010-81230
BOLT
19
01643-31232
WASHER
20
20Y-46-52130
SHEET
21
20Y-46-52150
SEAL
22
20Y-46-51162
SHEET
23
20Y-46-52141
SHEET
24
20Y-46-41170
GROMMET
25
20Y-46-51180
GROMMET
26
20Y-46-51190
GROMMET
27
20Y-46-51140
GROMMET
