Запчасти Komatsu PC200LC-6S ГЛАВН. КЛАПАН(№9999-9) ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
31
31
32
33
34
35
36
37
|1
702-21-09143
VALVE ASS'Y
1
BLOCK
2
VALVE
3
702-21-55460
SPRING
4
702-21-55420
O-RING
5
702-21-55430
O-RING
6
702-21-55440
O-RING
7
702-21-53120
FILTER
8
07000-11009
O-RING
9
702-21-55410
PLATE
10
01252-60820
BOLT
11
01643-50823
WASHER
12
702-21-55450
O-RING
13
BLOCK
14
SPOOL
15
SLEEVE
16
SPRING
17
SCREW
18
SPRING
19
WASHER
20
POPPET
21
702-21-55620
PLUG
22
07002-11423
O-RING
23
NUT
24
O-RING
25
O-RING
26
07002-11623
O-RING
27
702-21-55710
SEAT
28
702-21-55720
SPRING
29
04260-00793
BALL
30
07000-11009
O-RING
31
PLUG
32
702-21-55670
ORIFICE
33
702-21-55470
ORIFICE
34
01252-60520
BOLT
35
702-21-55480
FRANGE
36
07000-12020
O-RING
37
01252-61025
BOLT
