E-A ЭЛЕКТРИКА ОСНОВН. И КАБИНА ПРОВОДКАES

Запчасти Komatsu PC200LL-8 E-A ЭЛЕКТРИКА ОСНОВН. И КАБИНА ПРОВОДКАES ЭЛЕКТРИКА

Схема запчастей Komatsu PC200LL-8 - E-A ЭЛЕКТРИКА ОСНОВН. И КАБИНА ПРОВОДКАES ЭЛЕКТРИКА
5
4
5
4
4
5
6
4
4
6
5
3
4
2
13
12
1
11
15
10
7
24
28
30
29
26
14
27
27
27
25
26
16
22
9
20
17
23
15
21
14
19
1
18
8
FIT
1:1
100%

№

Артикул

Название

Примечание

Количество

1

20Y-06-A2241

HARNESS, CAB WIRING

2

08020-20000

DIODE

3

08041-00500

FUSE, 5 AMP

4

08041-01000

FUSE, 10 AMP

5

08041-02000

FUSE, 20 AMP

6

08041-03000

FUSE, 30 AMP

7

19M-06-31720

RESISTOR

8

20Y-06-31660

FUSIBLE LINK, 30 AMP

9

22U-06-11270

FUSIBLE LINK, 65 AMP

10

HM6400-0012

CONNECTOR, BLACK (F)

|$10

HM6409-0071

CONNECTOR, BLACK (M)

11

HM6400-0013

CONNECTOR, GREEN (F)

|$12

HM6409-0072

CONNECTOR, GREEN (M)

12

HM6440-0129

CONNECTOR, PINK (F)

|$14

HM6440-0128

CONNECTOR, PINK (M)

13

HM6400-0016

CONNECTOR, ORANGE (F)

|$16

HM6409-0075

CONNECTOR, ORANGE (M)

14

20Y-06-41283

CABLE

15

08038-00035

CAP, TERMINAL

16

20Y-06-22872

CABLE

17

08038-06031

CAP, TERMINAL

18

08088-30000

SWITCH, BATTERY RELAY

19

08038-00519

CAP, TERMINAL

20

08038-06031

CAP, TERMINAL

21

600-815-2170

SWITCH, HEATER

22

08038-00519

CAP, TERMINAL

23

600-815-8941

RELAY

24

08038-12027

CAP, TERMINAL

25

08038-42511

CAP, TERMINAL

26

08028-CC065

CABLE

27

20Y-06-A2231

HARNESS, MAIN FRAME WIRING

28

206-06-A1410

BRACKET

29

01010-81045

BOLT, MOUNT BRACKET

30

01643-31032

WASHER
