/ / / / / / TELESCO РУКОЯТЬ (ТРУБЫ)(№-)
Запчасти Komatsu PC200SC-6 TELESCO РУКОЯТЬ (ТРУБЫ)(№-) РАБОЧЕЕ ОБОРУДОВАНИЕ
1
1
2
2
3
3
3
3
4
5
6
7
8
9
10
11
12
13
14
15
15A
15B
16
16
16
17
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
33
33
34
35
35A
35B
35C
36
36
36
37
37
38
38
38
39
39
39
40
40
41
41
42
43
44
45
45
46
47
48
1
20Y-957-6120
TUBE,R.H.
2
20Y-957-6130
TUBE,L.H.
3
20Y-957-6140
TUBE
4
07372-21035
BOLT
5
01643-51032
WASHER
6
07000-13030
O-RING
7
20Y-957-6170
CLAMP
8
20Y-957-6180
CLAMP
9
01010-81065
BOLT
10
01643-31032
WASHER
11
01010-81045
BOLT
12
01643-31032
WASHER
13
20Y-957-6160
TUBE,R.H.
14
20Y-957-6150
TUBE,L.H.
15
07372-21035
BOLT
|15
01010-81065
BOLT
15A
07372-21045
BOLT
15B
07372-21060
BOLT
16
01643-51032
WASHER
17
07000-13030
O-RING
18
201-973-6810
NIPPLE
19
07002-13334
O-RING
|20
203-973-5802
VALVE ASS'Y
20
202-973-6380
O-RING
21
202-973-6930
RING
22
04025-00412
PIN
23
04064-03015
RING
24
203-973-3912
BODY
25
203-973-3922
SPOOL
26
07000-13025
O-RING
27
07001-03025
RING
28
01010-81075
BOLT
29
01643-31032
WASHER
30
20Y-957-1760
BRACKET
31
01010-81225
BOLT
32
01643-31232
WASHER
33
07121-20613
HOSE
34
201-62-27380
NIPPLE
35
07002-13334
O-RING
35A
20Y-957-5480
SWIVEL JOINT
35B
20Y-957-1470
UNION
35C
202-62-41270
NIPPLE
36
07020-00000
FITTING
37
205-70-51390
NIPPLE
|37
20Y-70-11540
CONNECTOR
38
20Y-957-6320
TUBE
|38
20Y-957-6210
TUBE
39
20Y-957-6330
TUBE
|39
20Y-957-6220
TUBE
40
20Y-957-6340
TUBE
|40
20Y-957-6230
TUBE
41
20Y-957-6350
TUBE
|41
20Y-957-6240
TUBE
42
21K-70-11310
CLIP
|42
21K-70-11310
CLIP
43
01010-80616
BOLT
|43
01010-80616
BOLT
44
01643-30623
WASHER
|44
01643-30623
WASHER
45
20Y-957-6360
HOSE
46
08036-01014
CLIP
47
01010-81020
BOLT
48
01643-31032
WASHER
