/ / / / / / FIG NO. C- СИСТЕМА ОХЛАЖДЕНИЯ
Запчасти Komatsu PC210LC-6L FIG NO. C- СИСТЕМА ОХЛАЖДЕНИЯ СИСТЕМА ОХЛАЖДЕНИЯ
22
19
25
24
23
18
27
26
29
21
37
20
2
38
1
8
40
29
7
21
20
41
13
42
36
28
31
32
43
13
30
6
11
5
3
4
39
10
15
9
4
17
16
10
14
12
14
17
33
35
16
17
34
16
32
31
30
1
20Y-03-21510
RADIATOR
2
205-03-71280
CAP, RADIATOR
3
205-03-62660
PLUG
4
07000-01007
O-RING
5
203-03-41411
HOSE
6
20Y-03-11330
CLIP
7
01010-51025
BOLT
8
01643-31032
WASHER
9
20Y-03-21480
SEAL
10
20Y-03-21490
SEAL
11
NS
BRACKET
12
NS
BRACKET
13
20Y-03-21320
SEAL
14
20Y-03-21410
STAY
15
20Y-03-21420
STAY
16
01010-61230
BOLT
17
01643-31232
WASHER
18
20Y-03-21121
COOLER, OIL
19
20Y-03-21330
SEAL
20
01010-51225
BOLT
21
01643-31232
WASHER
22
20Y-03-21430
SEAL
23
20Y-03-21141
NET
24
01434-10616
BOLT
25
01643-30823
WASHER
26
20Y-03-21430
SEAL
27
20Y-03-21520
SHROUD, FAN
28
01435-20816
BOLT
29
20Y-03-14110
SEAL
30
20Y-03-21380
PLATE
31
01010-51025
BOLT
32
01643-31032
WASHER
33
20Y-979-2831
BRACKET
34
01010-51025
BOLT
35
01643-31032
WASHER
36
20Y-979-2841
BRACKET
37
01010-51025
BOLT
38
01643-31032
WASHER
39
20Y-979-2820
BRACKET
40
01010-51020
BOLT
41
01643-31032
WASHER
42
20Y-03-21270
SEAL
43
20Y-03-21260
SEAL
