/ / / / / / FIG NO. M-A ЛЕВ. ДВЕРЬ КАБИНА - СТАНДАРТН. DUTY
Запчасти Komatsu PC210LC-6LC FIG NO. M-A ЛЕВ. ДВЕРЬ КАБИНА - СТАНДАРТН. DUTY ЧАСТИ КОРПУСА
48
46
48
49
49
45
48
48
49
49
44
19
39
41
15
40
16
36
35
38
37
17
32
21
47
20
31
29
48
30
28
34
49
23
35
43
24
8
4
42
26
34
49
27
5
25
50
6
33
22
9
35
35
11
18
33
7
12
2
8
10
4
14
13
1
3
1
20Y-54-28113
COVER
2
20Y-54-28161
HINGE
3
20Y-54-28270
SEAL
4
20Y-54-28281
SHEET
5
01010-51235
BOLT
6
01643-31232
WASHER
7
20Y-54-28290
PLATE
8
20Y-54-28341
COVER
9
20Y-54-28161
HINGE
10
198-54-41982
LOCK ASSEMBLY
11
20Y-54-28191
SHEET
12
205-54-53550
DOVE TAIL
13
01010-50612
BOLT
14
01643-30623
WASHER
15
01010-51235
BOLT
16
01643-31232
WASHER
17
20Y-54-28290
PLATE
18
20Y-54-29113
FRAME
19
20Y-54-29223
FRAME
20
01010-51230
BOLT
21
01643-31232
WASHER
22
20Y-54-28170
BRACKET
23
01010-51230
BOLT
24
01643-31232
WASHER
25
205-54-51970
DOVE TAIL
26
01010-50616
BOLT
27
01643-30623
WASHER
28
20Y-54-28181
PLATE
29
01010-51230
BOLT
30
01643-31232
WASHER
31
20Y-54-29232
BAR
32
20Y-54-29232
BAR
33
20Y-54-29241
SEAL
34
20Y-54-29251
SEAL
35
20Y-54-29261
SEAL
36
20Y-54-27341
BRACKET
37
01010-51230
BOLT
38
01643-31232
WASHER
39
20Y-54-12920
CLAMP
40
01010-51025
BOLT
41
01643-31032
WASHER
42
203-54-56710
STOPPER
43
01580-11008
NUT
44
20Y-54-KA160
FRAME
45
20Y-54-29271
SHEET
46
20Y-54-29143
FRAME
47
20Y-54-K7741
SHEET, INSULATION
48
01010-51230
BOLT
49
01643-31232
WASHER
50
20Y-54-K7991
SHEET, INSULATION
