Запчасти Komatsu PC210LC-7K ЦИЛИНДР РУКОЯТИ ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ
1
2
2
3
3
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
17
18
18
19
20
21
21
22
23
24
25
26
26
27
28
29
29A
29B
29C
29D
30
31
32
33
34
35
36
37
38
39
40
41
41
42
42
43
43
44
45
46
47
48
49
50
51
G1
707-01-XY441
CYLINDER GROUP
G1
707-01-XY440
CYLINDER GROUP
|1
707-01-0A311
CYLINDER ASS'Y
|1
707-01-0A310
CYLINDER ASS'Y
1
707-13-13540
CYLINDER
2
707-76-80470
BUSHING
3
07145-00080
SEAL,DUST (KIT)
4
707-58-95162
ROD,PISTON
|4
707-58-95161
ROD,PISTON
5
707-27-13961
HEAD,CYLINDER
6
07179-13109
RING,SNAP
7
707-56-95510
SEAL,DUST (KIT)
8
707-52-90720
BUSHING
9
707-51-95030
PACKING,ROD (KIT)
10
07000-15125
O-RING (KIT)
11
707-35-91370
RING,BACK-UP (KIT)
12
707-51-95640
RING,BUFFER (KIT)
13
01010-81875
BOLT
14
707-41-11840
WASHER
15
707-36-13771
PISTON
16
707-44-13280
RING,PISTON (KIT)
17
707-39-13530
RING,WEAR (KIT)
18
707-44-13920
RING
19
707-71-61070
PLUNGER
20
07000-15085
O-RING (KIT)
21
707-35-90960
RING,BACK-UP (KIT)
22
01310-01216
SCREW
23
707-71-70270
PLUNGER
24
07020-00000
FITTING,GREASE
25
707-71-32770
COLLAR
26
707-35-91370
RING,BACK-UP (KIT)
27
07000-15125
O-RING (KIT)
28
04260-00635
BALL
29
707-71-91270
CAP
29A
707-83-13010
VALVE
29B
07750-01628
SPRING
29C
707-87-14070
PLUG
29D
07002-12034
O-RING (KIT)
30
707-86-66270
TUBE
31
20D-62-17860
ELBOW
32
01435-01055
BOLT
33
01435-01040
BOLT
34
07000-13030
O-RING (KIT)
35
01435-01075
BOLT
36
07000-13035
O-RING (KIT)
37
707-88-22530
BRACKET
38
707-88-21261
BAND
39
01435-01030
BOLT
40
707-88-11560
PLATE
41
07283-22738
CLIP
42
01599-01011
NUT
43
01643-31032
WASHER
44
01643-51032
WASHER,(FOR SHIPPING)
45
07372-21035
BOLT,(FOR SHIPPING)
46
707-88-33030
HEAD,(FOR SHIPPING)
47
07371-30640
FLANGE,(FOR SHIPPING)
48
01643-51032
WASHER,(FOR SHIPPING)
49
07372-21035
BOLT,(FOR SHIPPING)
50
707-88-33040
CAP,(FOR SHIPPING)
51
07371-31049
FLANGE,(FOR SHIPPING)
K
707-99-57160
SERVICE KIT
