/ / / / / / РУКОЯТЬ (.M) (ДЛЯ LC) (№K9-)
Запчасти Komatsu PC210LC-8K РУКОЯТЬ (.M) (ДЛЯ LC) (№K9-) T РАБОЧЕЕ ОБОРУДОВАНИЕ
1
2
3
4
5
6
7
8
9
9
10
10
11
11
12
12
13
13
14
14
15
16
17
18
19
20
21
22
23
24
24
25
26
|1
20Y-944-K476
ARM
1
20Y-70-K4532
ARM
2
20Y-970-3570
BRACKET (WELDED)
3
20Y-970-7A10
PLATE (WELDED)
4
20Y-970-7A20
PLATE, L.H. (WELDED)
|4
20Y-970-7A30
PLATE, R.H. (WELDED)
5
20J-70-12180
SEAT (WELDED)
6
206-62-K2740
BRACKET (WELDED)
7
20Y-62-K7290
SEAT (WELDED)
8
20Y-70-32E50
SEAT (WELDED)
9
20Y-70-31272
BUSHING
10
20Y-70-32410
BUSHING
11
205-70-73180
BUSHING
12
07145-00090
SEAL
13
20Y-70-23220
SEAL
14
20Y-70-23230
SEAL
15
20Y-70-31160
PIN
16
20Y-62-K7651
PLATE
|16
20Y-62-K7650
PLATE
17
01010-81240
BOLT
|17
01010-81230
BOLT
18
01643-31232
WASHER
19
20Y-70-31431
SPACER, 1.0MM
20
205-70-71190
PIN
21
205-70-66580
PLATE
22
01010-81230
BOLT
23
01643-31232
WASHER
24
20Y-70-31381
SPACER, 1.0MM
25
20Y-70-31391
SPACER, 2.0MM
26
707-H1-X0080
CYLINDER GROUP
|26
707-F1-X0080
CYLINDER GROUP
|26
707-01-XR140
CYLINDER GROUP
|26
707-01-XJ150
CYLINDER GROUP
