Запчасти Komatsu PC220LL-7L FIG. K-A ХОД PPC КЛАПАН КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ
1
2
3
4
6
5
7
9
10
8
2
3
4
6
5
7
9
22
10
23
8
27
26
25
24
14
12
18
19
19
11
12
13
21
20
18
19
17
25
24
19
16
21
15
13
27
26
|$0
702-16-01861
PPC VALVE, TRAVEL
1
NSS
BODY, VALVE
2
NSS
VALVE
3
702-16-51140
SHIM, 0.30 MM
4
702-16-53420
SPRING
5
702-16-53140
RETAINER
6
702-16-54420
SPRING
7
702-16-53170
PISTON
8
702-16-51270
SEAL
9
07000-12020
O-RING
10
702-16-54170
COLLAR
11
702-16-54311
CASE
12
NSS
LEVER
13
NSS
SHAFT
14
NSS
PLATE
15
01010-80855
BOLT
16
01643-30823
WASHER
17
01010-80816
BOLT
18
04025-00432
PIN, SPRING
19
702-16-54430
BUSHING
20
702-16-54331
WASHER, 1.60 MM
|$21
702-16-54341
WASHER, 1.30 MM
|$22
702-16-54351
WASHER, 1.00 MM
21
702-16-54280
SEAL, DUST
22
702-16-54506
DAMPER ASSEMBLY
23
01252-60525
BOLT
24
702-16-54511
PLATE
25
04025-00420
PIN, SPRING
26
702-16-54520
LEVER
27
01224-40612
SCREW
