Запчасти Komatsu PC228USLC-3T-YT КАПОТ (YELНИЗ.)(№-) ЧАСТИ КОРПУСА
1
2
3
3
4
5
6
7
8
9
10
11
12
13
14
14
15
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
31
31
32
32
32
|1
22U-54-21180
COVER
1
COVER
2
198-54-41982
LOCK ASS'Y (WELDED)
3
22B-54-11130
HINGE (WELDED)
4
22U-54-21120
SHEET
5
22U-54-21131
SHEET
6
22U-54-21161
SEAL
7
01010-81225
BOLT
8
01643-31232
WASHER
9
22U-54-21642
FRAME
|9
22U-54-21641
FRAME
10
01010-81230
BOLT
11
01643-31232
WASHER
12
22U-54-21661
FRAME
13
22U-54-21840
BAR
|13
22B-54-11181
BAR
14
01643-31032
WASHER
15
04050-13018
PIN
16
205-54-51970
DOVE TAIL
17
01010-80612
BOLT
18
01643-30623
WASHER
19
205-54-53550
DOVE TAIL
20
01010-80616
BOLT
21
01643-30623
WASHER
22
22U-54-21150
BRACKET
23
01010-81230
BOLT
24
01643-31232
WASHER
25
20Y-54-28182
PLATE
26
01010-81230
BOLT
27
01643-31232
WASHER
28
22U-54-21170
BRACKET
29
01010-81230
BOLT
30
01643-31232
WASHER
31
01010-81230
BOLT
32
01643-31232
WASHER
